lldpe single layer agricultural mulch blowing film extruder
Parameters for lldpe single layer agricultural mulch blowing film extruder
Model | LD1100 | LD1300 | PC-65 | LD2200 | LD2500 | LD2600 | LD2800 | |||
Max. mulch film lay-flat width(mm ) | 1000 | 1200 | 1500 | 2000 | 2300 | 2500 | 2600 | |||
Mulch film thickness(mm ) | 0.005~0.008 | 0.006~0.009 | ||||||||
Output(kg/h ) | 50 | 55 | 210 | 130 | 180 | 220 | 240 | |||
Raw material | Virgin LLDPE, LDPE, LLDPE&LDPE blend compound | |||||||||
Screw diameter(mm ) | 45 | 50 | 55/65 | 65 | 75 | 75 | 90 | |||
Screw L/D ratio | 30 | 30 | 30 | 30 | 30 | 30 | 30 | |||
Max. screw rotation speed(r/min) | 130 | 130 | 130/130 | 130 | 110 | 110 | 100 | |||
Main motor mode | Frequency—conversion speed--regulating | |||||||||
Main motor power(KW) | 15 | 18.5 | 30/37 | 37 | 55 | 55 | 75 | |||
Die structure | Spiral die, processing in machining center | |||||||||
Max. haul-off and wind-up speed of mulch film(m/min ) | 120 | 120 | 120 | 120 | 100 | 80 | 80 | |||
Total power(KW) | 28 | 32.5 | 72 | 80 | 88 | 105 | 180 | |||
Overall dimension(m) | 6.2X2.3X5 | 6.4X2.5X5 | 6.6X3X6.8 | 7.5X2.5X 7.7 | 7.8X3.2X 10.5 | 8X3.5X10.5 | 13X4X19 | |||
Weight(KG) | 5200 | 5500 | 6500 | 8500 | 16000 | 19500 | 21000 | |||
Remarks: above configuration for your reference, final exact data based on your specific demands.
1. The line is used for produce agricultural mulch film with LDPE, LLDPE, HDPE and its compound as raw material.
2. Central feeding spiral die head, machining center processing, chrome plating, own design.
3. Extruders adopt sectionalized screw, with oblique barrier and the mixing screw head, stable function, reliable, own design structure, highly improve plasticizing ability.
4. Even 8 rollers winding, winding roller chrome plating, without corrosion within several years.
5. Available to produce mulch film with color transparent, black, stripped, both faces different color.
1. EXTRUDERS AND SCREEN CHANGER
|
2. DIE HEAD AND AIR RING
|
3. TRACTION PART
|
4. REWINDER
|
5. APPLICATION
|
Business nature: R&D manufacturer. |
|
Trade terms: EXW, FOB, CIF, CFR. | |
Payment terms: T/T, L/C, One-touch via Alibaba, 30% deposit in advance.
| |
Packaging: standard stretch film packing.
| |
Warranty: 12 months after installation.
| |
Shipping: ocean container transportation.
| |
Delivery detail: within 90 days after advanced deposit received. |
Agricultural film blowing machine made by Runhua Plastic Machinery Company, already successfully widely used by domestic large-scale manufacturer, such as Baishan Xifeng Plastic Limited Liability Company, Tianjin plastic Science & Technology Group Co.,Ltd, Beijing Huadun Snow Plastic Group etc. Therefore, many times win the bidding of large-scale bidding projects, such as CNPC, SINOPEC, Agricultural Bureau of middle west each provinces etc. Due to the improvement of longitudinal and transverse strength, agricultural mulch film made by enjoying good adaptation to severe weather.
Main products of Runhua: Agricultural film machine, Packaging film machine, Geo-membrane film machine, Plastic yarn extrusion machine, Plastic rope making machine, Plastic pipe extrusion machine.
12 months' quality guarantee, and we supply top quality and service. Engineers available to serve for customers overseas.
CONSULTING SERVICE
Different customers have different needs, you could tell us your special requirements, our engineer will design the machine as your require.
INSTALLATION SERVICE
Installation service are available with all new machine purchases. We will provide the technical konwledges to help you installing the machine, so you can put the machine into use as soon as possible.
CLIENT TRAINING SERVICE
We can train your staffs to use your equipment. First, we will trian your staffs use the equipment properly. Second, we will tell them how to use the raw materials to produce the film. Different materials and different proportions will lead to different films. After our training, you staff can produce any films you want.
AFTER-SALE SERVICE
We offer the persistent mantainence service and permenate technical assistance. It's benefit to the prevention of the problems and solveing questions as soon as possibe.
