Help CenterBSP G11/4 Compressor Speed Reducers Aluminum Liquid Oil Level Sight Glass Manufacturer
Related Products
-
BSP G Thread Round Aluminum Oil Sight Glass for Bizter With Flat Tempered GlassUS$ 0.68 - 10MOQ: 1000 Pieces -
Liquid Radiator Cooling System Round Aluminum Sight Glass (BSP G Thread & Metric Thread)US$ 0.68 - 10MOQ: 1000 Pieces
-
Aluninum Oil Level Sight Glasses OEM and ODM Service G3/4 InchUS$ 0.68 - 4MOQ: 500 Pieces
-
BSP Blower Aluminum Oil Sight Glass G3/8\" G1/2\" G3/4\" G1\"US$ 0.68 - 4MOQ: 500 Pieces
-
Aluninum Blower Oil Level Sight Glasses OEM and ODM Service G1/2 3/8 3/4US$ 0.68 - 4MOQ: 500 Pieces
GRAND-MFG sight glasses & breather vent plugs
Any special demands please just contact us and send detailed requirements for solutions.
Grand-MFG sincerely to support every customer, hope our quality parts help with your fulture business soon!
Aluminum Oil Sight Glass, Oil Level Indicator. Aluminum oil level gauge
Project Equipment offers valves, pipes, tubes, pipe fittings, etc.
The Aluminum Body Sight Glass or Oil level Indicator is provided with heat and oil resistance Viton rubber
It is capable of withstanding temperature of up to 120 degree C.
This Oil Level Indicator is used in all kinds of gear box, pumps, compressors, gear motor, hoists, hydraulic and pneumatic systems.
This Aluminum Body Sight Glass or Oil level Indicator is available in 1/4, 3/8, 3/4, 1 1/4, 1/2, 1 and 1 1/2 inches BSP,M10 to M48, Npt thread is available.
| item | aluminum sight glasses |
| material body | Aluminum 6061 T6/Aluminum 6063 |
| O-Ring | Viton,FKM,NBR, Aramid gasket and Copper seal |
| window | Natural Glass,Tempered Glass and Borosilicate Glass |
| Glass Thickness | 2mm to 5 mm |
| Reflectors | Stainless Steel 304 Reflector (Any type you can chose with reflector or without Reflector, You also can add float ball.) |
| Resist Tempreature Range | .-30'C TO 120'C |
| Pressure Range | 5-10 Bar(0.5MPa to 1 MPa). |
| Thread type | UNC,UNF,Metric and BSP(G thread) |
| size | Below you will get the size you wanted.Another size is okay. OEM are welcome. |
| Usage | Pump,Oil Receivers,Gearboxes,Speed Reducer,Compressor and Power Transimission. |
Any demands just contact us or vist our GRAND-MFG website to get details.Thank you.
