Help CenterHigh Voltage XLPE Power Cable
Related Products
Specifications
high voltage XLPE power cable1,Conductor: ALuminum,Copper
2,Insulation: XLPE
3,Jacket:PVC/PE
4,Armored:Option
high voltage XLPE power cable
Product Description
Conductor: copper (aluminum) stranded
Insulation: XLPE
Sheathed: PVC (PE)
Armored: steel tape/ steel wire /aluminum tape/ aluminum tape
Standard:
Products are produced and provided according to GB/T 12706.
Product features:
>Not drop restriction on laying
>Stable & process performance
>Strong ability to adapt to the environment
>Short circuit (the longest duration of not more than 5s)
>The highest temperature of cable does not exceed 250 °C
>The maximum normal operating temperature of conductor 70°C
>Good flexibility, easy maintenance, installation, simple structure
>AC rated voltage 0.6/1kv,50 HZ for the fixed installation , transmission and distribution lines.
No.of Core ×Cross-sectional Area (mm2) |
Approx.Outer Diameter (mm) |
Approx.Weight kg/km |
|||||||
Non-armoured |
Steel tape armoured |
Steel wire armoured |
YJV |
YJLV |
YJV22 |
YJLV22 |
YJV32 |
YJLV32 |
|
4×4 |
13 |
16 |
18 |
261 |
164 |
418 |
322 |
657 |
561 |
4×6 |
14 |
17 |
19 |
345 |
207 |
518 |
381 |
778 |
651 |
4×10 |
17 |
20 |
22 |
535 |
290 |
744 |
499 |
1064 |
819 |
4×16 |
20 |
23 |
25 |
783 |
390 |
1020 |
627 |
1532 |
1139 |
4×25 |
23 |
26 |
28 |
1167 |
550 |
1439 |
822 |
2029 |
1412 |
4×35 |
26 |
29 |
31 |
1547 |
694 |
1851 |
998 |
2502 |
1648 |
4×50 |
27 |
30 |
33 |
2090 |
912 |
2420 |
1241 |
3337 |
2158 |
4×70 |
31 |
35 |
37 |
2901 |
1214 |
3596 |
1909 |
4300 |
2613 |
4×95 |
35 |
40 |
42 |
3882 |
1570 |
4694 |
2382 |
5489 |
3177 |
4×120 |
39 |
43 |
46 |
4830 |
1927 |
5716 |
2913 |
7010 |
4108 |
4×150 |
43 |
48 |
51 |
6040 |
2395 |
7068 |
3423 |
8494 |
4848 |
4×185 |
48 |
53 |
56 |
7502 |
2961 |
8645 |
4104 |
10169 |
5628 |
4×240 |
54 |
59 |
62 |
9548 |
3695 |
10874 |
5022 |
12613 |
6761 |
4×300 |
59 |
65 |
68 |
11919 |
4554 |
13384 |
6019 |
15343 |
7979 |
4×400 |
66 |
72 |
77 |
15530 |
5859 |
171219 |
7548 |
20235 |
10564 |
