electricity wifi data transmission devices /rs232 to wifi converter /ethernet wf-01
Fast Access WiFi!
RS232 RS485 automatic switching!
RJ45 network connection, support wired Ethernet transmission!
Multiple applications for data transmission from wired to wireless!
WF-01 is a wireless networking router, which is used for project of RS232/ RS485 serial equipment to WIFI or Ethernet networking! Because of it, lots of industrial data transmission via serial to WIFI or Ethernet can be possible!
WF-01 provides a serial port to WIFI function, can be RS-232/485 converted into a TCP/IP serial network interface, RS-232/485 serial port and WIFI/ Ethernet bidirectional data transparent transmission.The serial device can transfer the data to TCP/IP network interface connect to the network for data communication, communication extended the range to serial device greatly!
WIFI TO RS232 / RS485/ RJ45 Ethernet Converter Features:
1.Can use as a Router;
2. Support Hardware AP, HTTPD Client and WEB IO;
3. Suport TCPB Function;
4. Fast Access WiFi;
5. Support hardware flow control (RTS/CTS) RS232 interface, male mouth(needle) consistent with computer pin definition;
6. RS232 RS485 automatic switching;
7. Support Webpage Configuration;
8. RJ45 network connection, support wired Ethernet transmission;
9. Rich status indicator light: Power/Ready/Link/RXD/TXD;
10. Reload button, do not worry incorrect settings(in working status, press the button 3s then it load to default settings and automatic restart);
11. Design with positioning hole, convenient installation;
12. Highest support baud rate 460800 bps;
13. Optional TCP Server/TCP Client/UDP Client/ UDP Server mode, the TCP Server mode can support up to 32 Client connection;
14. Multiple applications for data transmission from wired to wireless.
WIFI TO RS232 / RS485/ RJ45 Ethernet Converter Specifications:
1. Wireless standard:802.11 b/g/n
2.Antenna Option:External 3Dbi antenna
3.Operating voltage:5-18V (+/-5%)
4.Operating current:170mA~300mA
5.Operating temperature:-40℃- 85℃
6.Storage temperature:-40℃- 125℃
7.Dimensions:80×78×25mm
8.Security mechanisms:WEP/WPA-PSK/WPA2-PSK
9.Encryption:WEP64/WEP128/TKIP/AES
10.Work mode:Transparent Transmission
WIFI TO RS232 / RS485/ RJ45 Ethernet Converter Standard Packing List
>>> WF-01 WIFI Converter * 1
>>> Antenna * 1
>>> LAN Cable for 1 Meter * 1
>>> User Manual *1
>>> Packing size: 17*9.5*4 cm
>>> Gross Weight: 0.32kg
