SINOTRUK Low Bed Trailer QDZ9650TD

Specifications

1, Genuine spare parts;
2,We are factory, not sale company;
3, Have 60 years history;
4, Quality products and best services

Factory Outlook

Certificate:



Production line:

Products Specifications:



Dimension:

Total length: 12000mm(Excluding Ladder)

Width: 3200mm

Height: 1700mm(Excluding ladder)

Length of loading platform: 8000mm

Height of loading platform: 1100mm (unloaded)



King pin location: one position on 500mm from the front face of the front bolster

Fifth wheel height: 1340mm with the chassis level

Landing gear location: 2150mm behind the king pin

Tare weight (Tolerance 0-4%): approximate 8200kg

Payload: 65000kg

King Pin: φ90mm

Landing Gear: 2 speed road side winding with sand shoe, Lifting capacity 24T.

Type: Fuwa or Jost-Eagle

Suspension: Mechanical suspension with 10 leaf spring (90mm width by 16mm thickness/leaf).

Axles: Fuwa square axle with 15tons capacity.

Rims: 8.0-20 disc wheel, 13PCS; Supplier:Sunrise

Tires: 10R20, 13PCS; Supplier: Triangle

Brake System:Non ABS brake system

Brake Chamber: 30/30 type

Electric system: 24 volt lighting system with modular wiring harness, 7-pin socket
