Help Center90 Degree Belt Conveyor
US$ 1,000 - 4,999
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
leadworld
Model Number:
LW-90 degree belt conveyor
Payment & Shipping
Payment Methods:
Port of Shipment:
Fob Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Conveyor Belt DryerUS$ 1,000 - 9,999MOQ: 1 Set -
Conveyor ScannerUS$ 1,000 - 9,999MOQ: 1 Set
-
Supermarket Friction BeltNegotiableMOQ: 10 Pieces
-
Bakery Packing Machine,automatic Filling Sealing MachineUS$ 998 - 9,998MOQ: 1 Set
-
Bubble Packing Machine,automatic Filling Sealing MachineUS$ 998 - 9,998MOQ: 1 Set
Place of Origin
Shanghai, China
Brand Name
leadworld
Model Number
LW-90 degree belt conveyor
90 degree belt conveyor: B=500mm,800mm,1000mm, it can transfer stone and ore,
Application of 90 Degree Belt Conveyor
This machine is a continuously conveying equipment for general purpose materials in bulk and adopted belt with waviness sides and diaphragm plate. It is specially using for big inclined angle conveying.
It is widely using for coal, chemical industry, building materials, metallurgy, electric power, light industry grain, port, shipping, etc. Specific gravity of bulk materials is 0.5-2.5 t/m³ can be conveyed in the working environment where the temperature is during -15 degree to 140 degree.
Conveying materials which have special requirement, such as high temperature, materials
containing acid, alkali, oil substance or organic solvent should be conveyed using special
conveyor belt.
Partial Technical Parameter of 90 degree Belt Conveyor
|
Belt width (mm) |
Height of side way |
Distance between baffles (mm) |
Capacity Qv(m³/h)(mm) |
Max materials size and belt speed(sec) |
Power (Kw) |
Angle of inclination(°) |
500 |
80 |
126 |
11 |
1.0/50 |
15~18.5 |
90 |
252 |
- |
|||||
100 |
126 |
16 |
1.0/55 |
|||
252 |
- |
|||||
120 |
126 |
24 |
1.0/60 |
|||
252 |
- |
|||||
378 |
- |
|||||
650 |
100 |
126 |
23 |
1.25/55 |
1.5~22 |
90 |
252 |
-- |
|||||
120 |
126 |
34 |
1.25/60 |
|||
252 |
-- |
|||||
378 |
-- |
|||||
160 |
252 |
25 |
1.25/80 |
|||
378 |
- |
|||||
800 |
120 |
126 |
46 |
1.25/60 |
2.2~45 |
90 |
252 |
-- |
|||||
378 |
-- |
|||||
160 |
252 |
34 |
1.25/80 |
|||
378 |
- |
|||||
200 |
252 |
55 |
1.25/100 |
|||
378 |
36 |
|||||
504 |
- |
|||||
1000 |
160 |
252 |
45 |
1.25/80 |
4.0~75 |
90 |
378 |
- |
|||||
200 |
252 |
75 |
1.25/100 |
|||
378 |
48 |
|||||
504 |
- |
|||||
240 |
252 |
111 |
1.25/140 |
|||
378 |
73 |
|||||
504 |
- |
