Home > Industrial Equipment & Components > Conveyor & Parts > Conveyor > Conveyor Scanner

Conveyor Scanner

Conveyor Scanner thumbnail-1
Conveyor Scanner photo-1
US$ 1,000 - 9,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, conveyor scanner
Material:
Stainless Steel
Contact Supplier Request Quote Chat Now
Shanghai Leadworld Machinery Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, conveyor scanner
Material Stainless Steel
Material Feature Heat Resistant
Structure Other, conveyor scanner
Place of Origin Shanghai, China
Brand Name leadworld
Model Number LW001

Specifications

X-ray Baggage Scanners AT-6550
High penetration
,Detect gun, knife, bomb

Technical Specifications

Tunnel Size:650(W)*500(H)mm

Power Requirement::220VAC(±10%)50±3Hz

Power Consumption:1.0 KW (max)

Noise: <55db

Conveyor Speed:0.22m/s

Conveyor Max Load:100kg

Sensitivity: 42WG Typical, 40WG Guaranteed

Spatial Resolution: 1.0mm Horizontal and Vertical

Penetration resolution: dia 0.254mm

Penetration: 34mm Steel Typical, 32mm Guaranteed

Dose per Inspection: < 1.4μGy/h

X-ray Leakage:0.0μGy/h (at a distance of 5cm From external housing)

Film Safety: Guarantee ISO1600 Film

X-ray Generator Specifications

Voltage: 100KV to 160kv

Tube Current: 0.4mA to 1.2mA

Cooling: Sealed Di-Electric Oil Bath with Forced Air.

Duty Cycle: Rated for 100% Duty Cycle

Beam Direction: Upward

Beam anger:80 degree

Detector: 1024 Channels in an L-Shaped Array

Image Display

Single 17’’ High Resolution, low Radiation, Ergonomic LCD Color Monitor

Display Resolution: 1280*1024; 24 bit/pixel Color

Contrast Sensitivity: 24 Visible Levels, 4096 Gray Level

Image storage:60000 pictures in real time

Zones & Zoom:1-9 Image regions, 2,4,8,16 Times Enlarge, Whole screen continuous observation

Processing: Edge enhancement, image strengthening, image lightening, reducing darkening,image returning, image retrieval.

Multi-Energy (M) color material identification: Organic objects in orange, inorganic objects in blue, mixture in green

Environmental Specifications

Operating Temperature: 0°C-45°C

Storage Temperature:-20°C-60°C

Humidity: Up to 95% Non-Condensing

Computer Specifications

Processor: Intel(R)Dual CPU 2.0

Memory: 1GB RAM

Storage: 160GB HDD

Video Card: 256 Video Card (digital Display)

Platform: Windows XP Pro

Standard Features

Auto Image Archiving

Baggage Counter

Color and Black/ White Imaging

Density Alert

Edge-Enhancement Imaging

High Penetration

Image Annotation

Image review

Manual Archive (bitmap)

Suspect Image Archive

Operation Training Program

Picture Perfect

Print Image

Programmable Penetration

Programmable Contrast

Pseudo Color

Reverse Monochrome

Real-Time Image Manipulation

User Defined Access

Zoom 2X to 64X

High-energy/low energy: Switch from high energy to low energy

Assist to detect drug and explosive powder

Sound and light alarm;

l Protective cover on lead curtain to avoid lead pollution;

l Real time continuous self diagnostics

Physical Specifications

Tunnel Opening: 650mm W* 500mm H’

Dimensions:

1980mm L *880mm W *1280mm H (Main machine, exclude monitor)

630mm L * 900mm W *1220mm H(Operation counter)

1000mm L * 655mm W * 650mm H (Extension Exit Roller table)

6550 Crate Dims:

2010mm L *910mm W *1310mm H (Main machine, exclude monitor)

660mm L * 930mm W *1250mm H(Operation counter)

1030mm L * 685mm W * 680mm H (Extension Exit Roller table)

Gross weight: 700kgs
