Factory Directly Sale Chemical Glass Separation Evaporator With 50L Rotary Flask

Factory Directly Sale Chemical Glass Separation Evaporator With 50L Rotary Flask thumbnail-1
Factory Directly Sale Chemical Glass Separation Evaporator With 50L Rotary Flask photo-1
US$ 1,500 - 2,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Distillation
Power Source:
Electric
Contact Supplier Request Quote Chat Now
Shanghai Yuhua Instrument Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Distillation
Power Source Electric
Process Vacuum Distillation
Place of Origin Shanghai, China
Brand Name YH
Model Number RE-5002
Voltage 220V/50HZ
Power(W) 250W
Dimension(L*W*H) 1060*620*1200mm
Weight 200kg, 200kg
Certification CE
Warranty One year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Brief Introduction of Chemical Glass Separation Evaporator

Rotary evaporator is mainly used in concentrate, crystallization , drying, separation and solvent recovery in pharmaceutical, chemical, bio- pharmaceutical industries and others. Its principle is under vacuum conditions, constant heating and constant speed for rotating bottle, the material in the rotating bottle forms a large-area thin film, with efficient evaporation. Solvent vapor passes through efficient glass condenser with cooling and recycle collection, greatly improving the efficiency of evaporation. Concentrated purification for biological products, especially for high temperature easily decomposed.
Our rotary evaporator absorbs the essence of the domestic's product, with the success of our company's experience, has formed 500ml, 2L, 3L, 5L, 10L, 20L, 30L, 50L series, product design efficient, practical and economically.

Main Features of Chemical Glass Separation Evaporator

1. Motorized lift/ Electric lift heating bath
2. Water or oil can be choosed as heating medium
3. Build in vacuum meter
4. With digital display and control, also can be controlled by computer
5. Stainless steel structure, PTFE sealing, and 3.3 high borosilicate glass parts
6. With vertical or diagonal condenser, and the condenser is recylable
7. Variable inclination angle of evaporating flask
8. Ex-proof motor series is available
9. Customization service

Specification of Chemical Glass Separation Evaporator

Model
RE-1002
RE-2002
RE-3002
RE-5002
Rotary Flask (L)
10L
20L
30L
50L
Collection Flask (L)
5L Bottom Discharge
10L Bottom Discharge
20L Bottom Discharge
20L Bottom Discharge
Motor Power
180W
250W
Condenser Surface (㎡)
0.57
1
1.5
1.5
Rotation Speed (rpm)
3~110



Evaporating Speed（H2O）
>3L/h
>5L/h
>9L/h
>9L/h
Reachable Vacuum Rate
<133Pa (1.33mbar, 1 Torr)
Bath Power (kW)
3kW
3kW
6kW
6kW
Static Temp. Control Range& Wave（℃）
0-99(180) ±0.2
Power
Single Phase 220V/50HZ
Details Picture Show

EX-proof system is optional


Offer EX-proof motor, EX-proof inverter and EX-proof
intelligent temperature control box, meet the requirements
of Q/HA01-2005 standard. Ex level reach ExdllBT4. wiring
and safety measures per user needs.

Apply to modern pharmaceutical and chemical reaction test production.

The thermometer probe is optional


Pt100 temperature sensor is a kind of converting temp.
variables can transmit the standardization of the output
signal of the instrument. With LCD digital display
frequency conversion controller. Accurate temperature measurement, LCD temperature display screen, easy to read.

Vacuum controller is optional


During the process of evaporation, the negative pressure

always down due to the saturation vapor and the micro-

leak of the connections. To keep the negative pressure, users have to keep the vacuum pump working or control it manually. VC-100C vacuum controller can control the system vacuum, and solve these problems.

Low temperature chiller

5l~100l and -120℃~20℃ customer optional.

Heating oil bath

5l~100l and 99℃~200℃ customer optional.

Matched Equipments

Low Temperature Circulating Pump

Water Circulating Vacuum Pump

Packing & Delivery

Packing

-Treated wood case or carton case

-Both neutral and customized packaging can be available

Delivery

Depends on the dimensions of the package and your requirements, we can deliver the goods by air, by sea, by train or by express.

Our Company
Our Service

Warranty:

- One year from the deliver date


- Provide lifetime service for whole equipments

Customized Service:

- According to your requirements and practical application


- Find the best solution

- Beautiful and practical

-OEM Service


FAQ

1. Are you manufacturer or trading company?
We are professional manufacturer of lab instruments with a history of 7 years.

2. How to choose suitable equipment ?

You tell us your requirements (For example: capacity, temperature range, pressure, etc ),
we will recommend you the best suitable equipment.

3. What’s your delivery time?
Within 5 working days after payment confirmed, customized products need 10~15 working days.

4. How to solve the problem of your equipment?
Please send us email of the problem, pictures or a small video will be much better,
we will find the problem and tell you how to solve it.
If there is a broken, we will send you a new part, and it is free in the warranty period.

5. Do you still provide service beyond the warranty?
Yes. Our warranty is one year from the delivery date, we also provide service beyond the
warranty period, but it will not free for the broken parts.
