Slurry Filter Press, Best Quality and Turnkey Service!

Slurry Filter Press, Best Quality and Turnkey Service! thumbnail-1
Slurry Filter Press, Best Quality and Turnkey Service! thumbnail-2
Slurry Filter Press, Best Quality and Turnkey Service! thumbnail-3
Slurry Filter Press, Best Quality and Turnkey Service! thumbnail-4
Slurry Filter Press, Best Quality and Turnkey Service! thumbnail-5
Slurry Filter Press, Best Quality and Turnkey Service! thumbnail-6
Slurry Filter Press, Best Quality and Turnkey Service! photo-1
Slurry Filter Press, Best Quality and Turnkey Service! photo-2
Slurry Filter Press, Best Quality and Turnkey Service! photo-3
Slurry Filter Press, Best Quality and Turnkey Service! photo-4
Slurry Filter Press, Best Quality and Turnkey Service! photo-5
Slurry Filter Press, Best Quality and Turnkey Service! photo-6
US$ 5,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Automatic Grade:
Automatic
Production Capacity:
High Efficiency
Contact Supplier Request Quote Chat Now
Zhengzhou Dynnor Industrial Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Automatic Grade Automatic
Production Capacity High Efficiency
Place of Origin Henan, China
Brand Name DL
Model Number AM80/1250
Voltage 380V
Power(W) 5.5KW
Weight 10900 kgs
Dimension(L*W*H) 4830*1800*1600
Certification CE ISO
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Membrane filter press is a kind of dewatering equipment working in batches, applicable to various solid-liquid separation. Filter press is effective, easy to use, suitable for large filtration plants that requires a high degree of automation or centralized control, with filter pressure of 0.8 Mpa min.. The whole machine is designed with integration of machine, electricity and liquid, can realize automatic pressing, filtering, draining, squeezing, loosening, drawing board, and so on, with a high degree of automation, large production capacity, low liquid content in filter cake,  high unit output, requiring only very limited area for installation&operation. Widely used in petroleum, chemical industry, dye, metallurgy, pharmacy, food, paper making, coal washing,water treatment and sewage treatment and so on all kinds of solid-liquid separation is required.

Automatic filter press is on the basis of the pressure filter, according to user's different requirements for filter press equipment automation degree, choose to increase automatic plate system, auxiliary varicose arm of discharging slag system, single lever water flushing system, flap hydraulic system, PLC control system and other auxiliary facilities, in order to reduce the workers labor intensity, improve production efficiency.



Membrane Filter Press Models & Technical Data

Model Filter area (m2) Plate size (mm) Cake thickness (mm) Filter chamber voiume (L) Number of plates (pcs) Filtration pressure (MPa) Motor power
(Kw)		 Total weight
(kgs)		 Overall dimension
LxWxH(mm)
AM30/870 30 870×870 <= 35 498 23 >=0.8 2.2 3046 3880*1250*1300
AM40/870 40 623 30 3593 4270*1250*1300
AM50/870 50 789 38 4057 4790*1250*1300
AM60/870 60 955 46 4597 5310*1250*1300
AM70/870 70 1121 54 5136 5830*1250*1300
AM80/870 80 1287 62 5636 6350*1250*1300
AM50/1000 50 1000×1000 <=35 776 28 >=0.8 4 4352 4270*1500*1400
AM60/1000 60 943 34 4480 4770*1500*1400
AM70/1000 70 1109 40 5263 5130*1500*1400
AM80/1000 80 1275 46 5719 5560*1500*1400
AM100/1000 100 1608 57 6555 6410*1500*1400
AM120/1000 120 1941 69 7466 7260*1500*1400
AM80/1250 80 1250x1250 <= 40 1560 29 >=0.8 5.5 10900 4830*1800*1600
AM100/1250 100 1975 37 11750 5440*1800*1600
AM120/1250 120 2391 45 12600 6060*1800*1600
AM150/1250 150 2911 55 13620 6820*1800*1600
AM160/1250 160 3119 59 14470 7130*1800*1600
AM200/1250 200 3847 73 15320 8200*1800*1600
AM240/1250 240 4679 89 16170 9420*1800*1600
AM250/1250 250 4783 91 17020 9570*1800*1600
AM200/1500 200 1500x1500 <=40 3809 49 >=0.8 11 26120 7140*2200*1820
AM250/1500 250 4723 61 26930 7730*2200*1820
AM300/1500 300 5637 73 28160 8720*2200*1820
AM350/1500 350 6551 85 29600 10110*2200*1820
AM400/1500 400 7618 99 31500 11260*2200*1820
AM450/1500 450 8532 111 33400 12250*2200*1820
AM500/1500 500 9446 123 33380 13240*2200*1820
AM600/2000 600 2000x2000 <= 40 11901 85 >=0.8 15 54164 13030*3000*2500
AM700/2000 700 13838 99 58300 14390*3000*2500
AM800/2000 800 14945 107 62460 15770*3000*2500
AM900/2000 900 17713 127 66620 17150*3000*2500
AM1000/2000 1000 19651 141 70780 18530*3000*2500



Workshops



Slurry Filter Press, Best Quality and Turnkey Service!







Slurry Filter Press, Best Quality and Turnkey Service!



Slurry Filter Press, Best Quality and Turnkey Service!
