Chicken Manure Solid Liquid Separator
Introduction of chicken manure solid liquid separator:
The chicken manure solid liquid separator is widely used in livestock and poultry farms of livestock and poultry excrement (chicken manure, duck manure, pig dung, etc.) of solid-liquid separation dehydration processing, the solid liquid separator is mainly composed of: stainless steel mesh, stainless steel spiral twisted dragon, stainless steel spiral blade adopts high quality 304 stainless steel manufactured through special process, have the characteristics of corrosion resistant and so on. Now I work the screw extrusion type continuous solid-liquid separation processor, using 0.5 mm, 0.75 mm and 1.0 mm and so on the aperture of mesh filter.
Working principle of chicken manure solid liquid separator:
If the material has too much water can the discharge pipe into the jungle fowl stirring the material also played a role in a cesspool, isolated by the screw extrusion filtering waste water can be directly sent to the settling basin, etc. In order to grasp discharging speed and water content, can adjust the host at the bottom of the counterweight block, in order to achieve satisfaction proper discharge state. Solid liquid separator high level automation, simple operation, easy maintenance, large capacity, low power consumption, suitable for continuous operation. Equipment weight and a half tons and the appearance of small size, is the ideal waste treatment equipment, large-scale chicken farms can greatly improve the efficiency of chicken manure treatment.
Features of chicken manure solid liquid separator:
The solid liquid separator has small volume, low speed, simple operation, convenient installation, maintenance and cost province, high efficiency, investment recovery fast, do not need to add any flocculant and other characteristics; The processor USES the high strength screw axis, decay resistance alloy spiral vane, screen mesh for the production of high quality stainless steel, spiral dragon blades made of a special process is two to three times the service life of the other similar products.
Advantages and effects of chicken manure solid liquid separator:
The raw material for adult chicken chicken manure, chicken rate of high and low impact chicken manure the content of organic matter and NPK. Chicken rate is high, the low content of organic matter and NPK dung; Chicken rate is low, it is a high content of organic matter and NPK dung.
5, at the same time to make a good feed the fish.
6, selling organic fertilizer can obtain additional economic benefits. Dry chicken manure optimum in litchi, longan, banana, mango, pineapple, sugar cane, betel nut, melons, beans, pepper, tomato, and so on, all have significant stimulation effect!
Technical specification of chicken manure solid liquid separator:
Name | Specification |
Model | TS-4, TS-5.5, TS-7.5 |
Main machine motor power | 4kw, 5.5kw, 7.5kw |
Pump motor power | 4kw |
Mainframe construction material | Stainless steel |
Input flow amount | 5-8, 10-16, 15-25 |
Washing water consumption | 0.2m3 |
Washing frequency interval | 20days |
Max input solid content | 35% |
Max output moisture | 40-60% |
Filting net hole size | 0.3/0.6/1.0 |
