Dongfeng Asphalt Distribution Truck / 4x4 Asphalt Distributor Truck / Dongfeng Bitumen Sprayer 5m3
Distribution truck drive system:4x4
Distribution trucks main market : West Africa.
1:Dongfeng Duolika ibearing chassis is adopted if your steering wheel on the left side.But If your steering wheel on the right, then the chassis is JAC.
2:Original wedge positioning staineless steel combination nozzle sprays in the fan-shaped area and positions accurately. It is wear-resisting and the quality is reliable. It is fast and convenient to replace.
3:Equipped with high power auxiliary generator.
4:Post injection switch can be turned on with one button. The operation is more convenient.
5:Asphalt pipeline has systemic cirulation. It is suitable for spraying emulsified asphalt and heated asphalt.
6:PTO power take off method is used. Zero distance spraying can be realized.
7:Three overlapping spraying ensures more uniform spreading with higher precision.
4x4 Distribution truck specification:
Name |
bitumen distributor truck | Model No. |
CLW5180GGY | |
Max Gross Weight (kg) |
15790 | Curb weight (kg) |
8120 | |
Load weight (kg) |
7475 | Haul weight (kg) |
/ | |
Dimension (mm) | ||||
Overall dimension |
8990x2300x3000 | Box dimension |
4200x1960x1540 | |
wheelbase |
5200 | Wheel tread |
1836/1640 | |
Tank/box volume |
8cbm | Height of lifting (m) |
/ | |
Engine specifications | ||||
Model |
ISDe160-30 | Displacement (ml) |
4500 | |
Max power (kw) |
118 | Manufacturer |
Cummins | |
Emission Standard |
Euro III | Engine type |
diesel | |
Performance | ||||
Top speed (km/h) |
99 | Fuel consumption/100km |
/ | |
Spring suspension |
11/13+8 | Tire model |
9.00-20 | |
others | ||||
Air conditioner |
optional |
Drive type |
Left or Right |
|
More photos of asphalt distribution trucks for reference:
Please E-mail me for more specifications, photos for 4x4 asphalt distribution trucks
Welcome to visit our factory :
