2008 Hyundai Mixer Truck with construction Concrete Pump,9m3 Hyundai Hd270 Truck

Item

unit

Parameter

Vehicle model

DONGFENG Mixer Truck (LHD)

Horse Power

ps

340

Overall dimensions

mm

9650×2500×3950

Fact cubage

L

9000

GVW

kg

25000

Rated loading capacity

10805

Mass in working order

14000

Wheel base

mm

3800+1350

F/R track base

2050/1850/1850

Approach/departure angle

°

30/16

Exhaust/hp

ml/kw

9460/250

Max speed

km/h

85

Tire specification

11.00-20

Engine type

dCi340-30

Traction system

6*4

transmission

8-speed with over drive

Number of axles

2

Electric system

24v

Operation control  system

Electrically hydraulic control

Allowable passengers in cab

3

Equipment

Material And Technology

Italy ARK motor

Excellent National standard 16 M steel  5mm boom 6mm.

Italy hydraulic pressure oil pump

Automatic submerged arc welding.

TOP68 Reducer

Cold Forming Technology.

German AKG radiator

Hyperboloid stirring blades.

Drum Technical data

Drum Transmission Capacity

Charge Ratio

Charging Speed

Discharge Speed

Discharge Residual Rate

Drum Rotation Speed

9000 L

0.6

≥3M³/ min

≥2M³/ min

≤0.8 %

0~16 r/min

Filling Height

Discharging Minimum Height

Axes Angel

Overall Dimension

Normal Working Temperature

2.6 M

1.2 M

12±0.5

5.4*2.3*2.6

50°C~70°C

Engine

Cummins diesel engine, dCi340-30

Production cycle

15-20 days

Warranty

12 months
