Refrigerated Freezer Truck,Mini Fridge,Fridge Freezer
This truck can be widely applied tovarious types of transport refrigeration insulation needed goods, such as supermarkets, cold storage, food plants, pharmaceutical companies and so on.
Note :
1.ini ice cream van adop fully enclosed composite structure, inside and outside FRP, middle polyurethane foam heat insulation material, all-around is bonded together with high stength glue ,overall thickness is 10cm.(optional 20cm)
2. Appearance of smooth, flame retardant type insulation material , food-grade gelcoat, seamless whole panel
3. "CLW" seried refrigeration truck have features such as corrosion-resistant, good insulation properties, high strength ,light weight,good chemical stability, long life,etc.
4. Factory direct sale,professional, This Truck adop Forland 4*2 truck chassis with 88hp engine, economical, practical, Min temperature be dropped to -18°C
Remarks:
A. Refrigeration unit Brand Optioanl : American CARRIER ,THERMO KING, South Korea hanya, China Songhan, hanxue,etc.
B. Minimum temperature optional: -5 °C to -18 °C
C. The refrigeration units that we select have simple structure, convenient operation , reliable working, low energy consumption ,large refrigerating capacity, small noise , easy installation and maintenance and other advantages, it will sure you use safe!
Pls call me : Ms.Joyce tel: 0086-13545915671
| Main technical parameters | Name | refrigerator truck | Outline size(mm) | 7000x2220x3400 |
| Model | Dongfeng | Gross weight(kg) | 11495 | |
| Engine model | CY4102-E3C | Loading weight(kg) | 7000 | |
| Emission/ ( ml/Kw) | 3856ml/70kw, 95hp | Curb weight(kg) | 4300 | |
| Engine type | Diesel, 6 Cylinders, Direct line, Turbocharge and water cooling | |||
| Fuel type | diesel | Wheelbase(mm) | 3800 | |
| Max speed(km/h) | 95 | Tire model / number | 8.25R20 / 6 Units | |
| Operation control system | Electrically hydraulic | Transmission | 6 speed | |
| Traction system | 4x2 | Electric System | 24v | |
| Approaching angle(°) | 24 | Front / rear track(mm) | 1770/1640 | |
| Departure angle(°) | 12 | Front/rear hang(mm) | 1210/1990 | |
| Upstructure configuration | Transport medium | petrol/ diesel | Box material | glass fiber reinforced plastics |
| Tank available Capacity | 7 tons | Tank size: | 5050x2040x2050 | |
| Barrier material | Q235A | Air condition | yes | |
| Ground clearance | 450 mm | Temperature | -20℃ | |
| Steering mode | powe steel | Brake | oil/air | |
Ice cream truck material: fiberglass as below:
We highly recommend this refrigerator truck .
It’s in an excellent condition and as it was made by CLW, you can trust on driving it with high stability.
Since our inspection is very strict, all of our trucks’ durability is very long.
We have many connections with truck companies internationally. So if you want some other model than this truck We are sure that we can find one that is suitable for you.
Chengli Special Automobile Co., Ltd has earned a firm credibility around the world through excellent customer service. The company also provides attractive prices for high quality goods.
The above information is just for your reference. We can manufacture the trucks as per your request,Please feel free to contact us via email or phone if you have any inquiries.
