CLW 3 Axles Fuel Tanker Trailer 46000 Liter

CLW 3 Axles Fuel Tanker Trailer 46000 Liter photo-1
US$ 21,500 - 29,800 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Semi-Trailer
Material:
Steel
Certification:
Other, 3c
Payment & Shipping
Payment Methods:
Port of Shipment:
any port in China
Delivery Detail:
Delivery time depends on order quantity.
Type Semi-Trailer
Material Steel
Certification Other, 3c
Size 10000*2500*3950
OEM No. CLW9402
Max Payload 39000kg
Place of Origin Hubei, China
Brand Name CLW
Model Number CLW9402

CLW 3 axles Fuel Tanker Trailer 46000 Liter







                                                 CLW 3 axles Fuel Tanker Trailer 46000 Liter



            Fuel Tanker Trailer is also called mobile tanker semi trailer,tanker semi trailer truck,oil semi trailer truck,etc, widely used in gasoline,crude,lubricants,coal tar and other flammable gases's transportion and storage. We can supply Fuel Tanker Semitrailer ranged from 30000L to 6000L, Fuel tanker ranged from 4000L to 45000L, Experience of  more than ten years of manufacturing pressure vessel ensure reliable quality.





Production Notes:



1. ISO9001,3C
2 Factory direct sale, low price
3 10 year' Professional technology
4 Load 46000L gasoline or diesel



Main Parameter of   CLW 3 axles Fuel Tanker Trailer 46000 Liter



Main Technical parameter

Product Model

CLW Fuel Tanker Trailer

Overall Dimension(L*W*H)(mm)

10000×2500×3950

Tank Volume(L)

460000

Tank Dimension(mm)

Front-end( 3050*2480*1900 )

rear-end( 6650*2480*2100 )

Gross weight (kg)

Approx 49000

Approach/ departure angle (° )

-/18

Payload(kg)

Approx 39000

Front/ rear suspension(mm)

-/1860

Curb weight(kg)

10000

Leaf Spring number:

-/8/8/8, -/10/10/10

Axle number

3

Front/Rear axle load(Kg)

-/39000 (three-axis combined)

Wheelbase(mm)

4850+1310+1310

Rear tread(mm)

1840/1840/1840

Tire size

11.00R20 12PR or 12R22.5 12PR

Number of Tire:

12

Warranty

12 months, from the date of supply

Remarks

1. Protective material: carbon steel, storage medium: gasoline or diesel

2. Equipped with 2 oil pipe, one compartment, one gravity valve,one rear ladder , optional more compartment or optional add one oil pump

3.Tank material: 6mm carbon steel, optional stainless steel, Aluminum Alloy,

 4.  Equipped with one tool box, two fire extinguisher, ground wire,90# King pin ,28ton manual outrigger, ABS, optional one water tank















































































 Multi-faceted Show of  CLW 3 axles Fuel Tanker Trailer 46000 Liter :



 CLW 3 axles Fuel Tanker Trailer 46000 Liter

 CLW 3 axles Fuel Tanker Trailer 46000 Liter

 28 Ton Outrigger of  CLW 3 axles Fuel Tanker Trailer 46000 Liter :



 CLW 3 axles Fuel Tanker Trailer 46000 Liter :



3 FUWA 13ton axle combined of CLW 3 axles Fuel Tanker Trailer 46000 Liter :



CLW 3 axles Fuel Tanker Trailer 46000 Liter



Discharge Outlet of CLW 3 axles Fuel Tanker Trailer 46000 Liter :



CLW 3 axles Fuel Tanker Trailer 46000 Liter



Tool Box of CLW 3 axles Fuel Tanker Trailer 46000 Liter :





CLW 3 axles Fuel Tanker Trailer 46000 Liter





Fire extinguisher box and ground Anti-static tape of CLW 3 axles Fuel Tanker Trailer 46000 Liter :



CLW 3 axles Fuel Tanker Trailer 46000 Liter



More  Fuel Tanker Trailer show as the following:



CLW 3 axles Fuel Tanker Trailer 46000 Liter



CLW 3 axles Fuel Tanker Trailer 46000 Liter



Brief Introduction of Company:



        ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It has registered trademark"CHENLIWEI" and the products code is CLW. It has solid technology,flawless inspection,advanced equipments,reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 and the 3C Certification(China Compulsory Certification) and other certifications that export needed.

          Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks have always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea.

         We can design and produce many kinds of special trucks accurately as your request. Our company own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc. We strives for the survival by the quality and credit standing is the guarantee of our success.

            ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.
