Fecal Tank

Chengli Special Automobile Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Transmission Type:

Manual

Condition:

New

Emission Standard:

Euro 2

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Transmission Type Manual

Condition New

Emission Standard Euro 2

Fuel Type Diesel

Tank Volume 9000-11000L

Dimension (L x W x H) 7890x2470x3080

Place of Origin Hubei, China

Brand Name CLW

Model Number CLW5141GXE

Horsepower 150

Specifications

fecal tank with high vacuum
fecal tank with high efficency
fecal tank with 9000L

overall dimension:7890×2470×3080

fact cubage:900L-11000L

	unit	parameter
Vehicle model		CLW5108GXE fecal suction truck
Chassis model		EQ1108G6DJ16
Horse Power	ps	120
Overall dimensions	mm	7890×2470×3080
Fact cubage	L	9000-11000L
GVW	kg	Approx14495
Rated loading capacity		Approx 7000
Mass in working order		Approx 7295
Body internal dimensions	mm	420020101300
Wheel base		4500
F/R track base		1750/1586
Approach/departure angle	°	34/18
Exhaust/hp	ml/kw	5880/132
Max speed	km/h	90
Tire specification	100-20	Engine type	YCE140-20
Traction system	4*2	transmission	5-speed with over drive
Number of axles	2	Electric system	24v
Operation control system	Electrically hydraulic control	Allowable passengers in cab	2
Equipment	Equipped with special vacuum pump(rating rotate speed=1400r/m,min rotate speed 800r/m.max suction lift6m, vacuum500mmHg,clockwise) Equipped with power take off. Transmission shaft,high pressure sewage tank,pipe network, sewage pipe for observing and cleanuot equipmen Time for full sucktion 5min.
Engine	cummins
Production cycle	10-15days
Warranty	12 month, from the date of supply
