Specifications
high-capacity fecal suction truck1.vacuum suction pump
2.automatic suckings&dumping
3.max suction lift>6 within 5min
4.3C
Fecal suction truck
CLW5108GXE
CLW Special Automobile CO.,LTD offer a variety of suction volume of fecal collection vehicle.
1. Special part is composed of PTO, transmission shaft, vacuum pump, fecal tank(5mm), pipe reticulum, pressure gage, visible forms, washing hand device.
2. Fecal suction tube can be rotated 360.
3. Widely used in large , medium and small cities and towns sanitation, government, agriculture, chemical industry, factory, mining enterprises and courtyard.
4. More equipment optional.
Main specification of this fecal suction truck is as follows:
Item | unit | Parameter | |
Vehicle model |
| CLW5108GXE Fecal suction truck | |
Chassis model |
| EQ1108G6DJ16 | |
Horse Power | hp | 160 | |
Overall dimensions | mm | 7590×2470×2810 | |
Fact cubage | L | 7000-8000 | |
GVW | kg | Approx 10495 | |
Rated loading capacity | Approx 5000 | ||
Mass in working order | Approx 5300 | ||
Body internal dimensions | mm | 4200×2010×1300 | |
Wheel base | 3950 | ||
F/R track base | 1900/1800 | ||
Approach/departure angle | ° | 30/18 | |
Exhaust/hp | ml/hp | 5880/105 | |
Max speed | km/h | 90 | |
F/R Suspending hanging | mm | 1250/2930 | |
Axle-load | 3395/7100Kg | Spring few films | 8/10+7 |
Tire specification | 9.00-20 | Engine type | EQB160-20 |
Traction system | 4*2 | transmission | 5-speed with over drive |
Number of axles | 2 | Electric system | 24v |
Operation control system | Electrically hydraulic control | Allowable passengers in cab | 3 |
Equipment | Equipped with vacuum pump(rating rotate speed=1400r/m, min rotate speed800r/m, max suction lift6m, vacuum500mmHg, clockwise) Equipped with power take off, transmission shaft, fecal tank, pipe network, fecal pipe for observing and cleanout equipment Time for full suction5min | ||
Engine | DONGFENG Cummins, diesel engine | ||
Production cycle | 7-10 days | ||
Warranty | 12 month, from the date of supply | ||
fecal suction truck, sewage suction truck.fecal tanker truck.
For more detail. Pls contact with Nicole Yang by
Mobil phone:0086-15927388175
TradeManager : cn200802567
Hubei ChengLi Special Automobile Co., Ltd
ADD: South Suburb ChengLi Vehicle Industry Park, SuiZhou, Hubei Province, China.
