130 hp 4*2 Forland 5m3 Concrete mixing Truck
5m3 Concrete mixing Truck , is also called cement truck, concrete mixing truck, cement mix truck, concrete mixing transport truck, mainly used in transporting mixed concrete used in construction with mixing drum. We can manufacture cement mixer truck from 3m3 to 16m3, Cement Mixer Truck can select DONGFENG, SHACMAN, FAW, FONTON, HOWO, etc.
Product Notes:
1. This truck adopt plow shape mixing angle, perfect carbon steel, rugged wear;
2. Feed,discharge fast speed, stir well;
3. Main component adopt imported Italy PMP equipment or Chinese hydraulic equipment, high quality
4. FONTON Forland 4*2 chassis, Yuchai 130hp, mixing volume: 3-5m3
5. Competitive price
Main Parameter of 130hp 4*2 Forland 5m3 Concrete mixing Truck
Main technical parameter | |||
Product Model |
Forland 5m3 Concrete mixing Truck |
Product Brand |
FONTON FORLAND |
Mixing Volume(m3) |
3-5 |
Overall Dimension(L*W*H)(mm) |
6825×2480×3450,3600 |
Curb weight(kg) |
11815 |
Wheelbase(mm) |
3600 |
Axle number |
2 |
Max Speed (km/h) |
80 |
Cab type |
Flat proof, one and half row, heater |
Cab capacity |
3 |
Chassis Technical Parameter | |||
Chassis Model: |
BJ5142GJB-G1 |
Chassis Manufacturer: |
BEIQI FONTON Motor Co., Ltd |
Gear box |
5 shift with Subtransmission |
Transmission type: |
Manual |
Steering Type |
LHD or RHD with hydraulic power steering |
Traction Type: |
4*2 |
Brake System |
Air brake, Exhaust brake, breathe brake |
Leaf Spring number: |
9/11+9 |
Number of tire |
6 with a spare |
Tire size/type |
8.25-20 16PR,8.25R20 16PR, |
Engine specification | |||
Engine Model: |
YC4D130 |
Engine Brand |
GUANGXI YUCHAI |
Emission stand |
Euro 3 |
Displacement(ml) |
4200 |
Fuel type: |
Diesel |
Power(kw) |
96(130hp) |
Superstructure parameter |
1.Equipped with 24V Electric system, electrically hydraulic operation control ,Tanker Material: Q345, thickness: 5mm |
||
2. Equipped with Italy PMPhydraulic pump, hydraulic motor, speed reducer | |||
Multi-faceted of 130hp 4*2 Forland 5m3 Concrete mixing Truck:
Imported Italy PMP Hydraulic Motor and Hydraulic Pump , speed reducer:
Radiator :
200 L Water Tank :
Operating lever :
Air pessure water supply :
Brief Introduction of Company:
ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It has registered trademark"CHENLIWEI" and the products code is CLW. It has solid technology,flawless inspection,advanced equipments,reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 and the 3C Certification(China Compulsory Certification) and other certifications that export needed.
Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks have always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea.
We can design and produce many kinds of special trucks accurately as your request. Our company own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc. We strives for the survival by the quality and credit standing is the guarantee of our success.
ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.
Our Certificates:
Production Equipments:
Other Concrete Mixing Truck series:
Contact Information:
If you have any questions, pls feel free to contact with me via e-mail or phone, I will try my best to help you. You can count on me. Please remember as below:
