DY High Efficient Gold Stone Grinding Machine Price

Xinxiang Dayong Vibration Equipment Co., Ltd. Gold Verified Supplier
5Yrs
DY High Efficient Gold Stone Grinding Machine Price thumbnail-1
DY High Efficient Gold Stone Grinding Machine Price thumbnail-2
DY High Efficient Gold Stone Grinding Machine Price thumbnail-3
DY High Efficient Gold Stone Grinding Machine Price photo-1
DY High Efficient Gold Stone Grinding Machine Price photo-2
DY High Efficient Gold Stone Grinding Machine Price photo-3
US$ 999 - 19,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Roller Crusher
Application:
ore,mining,construction
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANJIN OR QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Roller Crusher
Application ore,mining,construction
Motor Type AC Motor
Power(W) 2*37000
Capacity(t/h) 60-140t/h
Place of Origin Henan, China
Brand Name DY
Model Number 2PG1600*1000
Dimension(L*W*H) 8220*2680*2475
Weight 41.2t
Certification CE,ISO9001:2008
Warranty 18 months
After-sales Service Provided Engineers available to service machinery overseas

DY high efficient gold stone grinding machine price

Product Description



DY high efficient gold stone grinding machine price

DY high efficient gold stone grinding machine priceDY high efficient gold stone grinding machine price



Working Principle of hard stone roller crushing machine:



This equipment adopts two motors, which take two rollers to rotate reversely by the decelerator. When the materials drop on the rollers through the feeding hole, under the friction of the rollers, they are dragged between the rollers, grinded by the roller's and crushing, the crushed materials are pushed rotatorily by the rollers.





Features:



hard stone roller crushing machine

1.The mud-scraping device can prevent materials from adhering to the roller, so the teeth surface can be more clean and the proper shearing and pressing be maintained;
2.Fixed spacing between 2 tooth rollers makes it stable to discharge;
3.Reasonable design for the shape of tooth plate and high-qualified wear resistant material extents its working life;
4.The movable and fixed rollers are interconnected by the coupling, thus obviating the frequent replacement of the belts;
5.With sensor, the machine can load relief when overload, so that to protect the machine.





Technical parameters of hard stone roller crushing machine:



Model

Feeding Size
(mm)

Output
Size
(mm)

Capacity
(t/h)

Motor Power
(kw)

Weight
(t)

Overall Dimension
(mm)

2PG400*250

<35

≤2-8

2-10

2*5.5

1.3

2110*870*810

2PG610*400

<65

≤2-20

5-20

2*15

3.9

3510*1420*1030

2PG750*500

<75

≤2-25

10-40

2*18.5

9.5

4210*1630*1260

2PG800*600

<80

≤2-25

12-45

2*22

10.8

4505*1780*1320

2PG1000*700

<100

≤3-30

20-65

2*30

14.9

5310*2175*1595

2PG1200*800

<120

≤3-35

35-80

2*37

25.5

6290*2270*1870

2PG1500*800

<130

≤3-45

50-120

2*75

33.7

7460*2410*2290

2PG1600*1000

<150

≤3-50

60-140

2*90

41.2

8220*2680*2475





Application scope of hard stone roller crushing machine:



Roller crusher is mainly used to crush material below the medium hardness, such as clinker mineral, coke, slag, shale, limestone and so on. It is the most suitable for small and medium non-metal mines and chemical industries to undergo secondary and fine crushing.









In order to give you a responsible quotation, you can inform us the following information:



1).  What's the material you are going to deal with?



2).  What's the granularity of the material?



3).  What's the granularity of the final products are you going to achive?



4).  What's the producing capacity you are going to achieve?



Our engineers will suggest you the most suitable one for you according to your information



Profile:



Dayong vibration Equipment CO.LTD supplys high quality DY series vibration equipment,crusher,conveyer,etc.which is also the first domestic manufacturer of vibrating screen equipment .Our company is a new-type shareholding system company which combines several decades of manufacturing experience and modern technology together.





Please feel free to contact us if you have interest in our products.



Mob:+86-156 3733 1601 Tel:+86-373-3669005   Fax:+86-373- 3669006



Skype:xinxiangdayongmary



Welcome to visit our factory and look forward to your cooperation.
