gold ore cone breaker machine
1. gold ore cone breaker machine usage and application
Cone crusher can be widely used in metallurgical, construction, chemical and building material industry , suitable for hard and medium hard material such as mine ore, limestone, quartz, granite, sandstone and so on .
2. gold ore cone breaker machine features
1.Hydraulic system is reliable, provide safe and effective overload protection ;
2.Use hydraulic adjustmeng and hydraulic clean cavity setting, much increase automation ;
3.The lubrication unit is interlock with the main motor for additional safety as a standard equipment ;
4.The spring safety system of crusher acts as an overloading protection system that allows metals to pass through the crushing chamber so as not to damage the Cone Crusher ;
5.Cone crusher has high design and manufacture quality long service life convenient repairing , lower cost . All of the maintenance work can be done easily on the top of the machine ;
6.Equipped with fully hydraulic system.Therefore operation is very easy; especiallytramp iron release is very quick and sensitive .
3. gold ore cone breaker machine principle
Cone crusher consist of frame, transmission device, hollow eccentric shaft, bowl-shaped bearing, crushing cone, springs and hydraulic pressure station for adjusting discharge opening.During operation, the motor drives the eccentric shaft shell to turn around through ahorizontal axle and a pair of bevel gear. The axle of crushing cone swings with the force of eccentric shaft shell so that the surface of the crushing wall is close to the roll mortar wall from time to time.
4.principal technical data of gold ore cone breaker machine
Model | Diameter of Cone(mm) | Max Feed Size(mm) | Output Range(mm) | Capacity(t/h) | Power(Kw) | Weight(t/h) | Dimension(mm) |
PYB-900 | 900 | 115 | 15-50 | 50-110 | 55 | 10.8 | 2692*1640*2350 |
PYZ-900 | 900 | 60 | 5-20 | 20-65 | 55 | 10.8 | 2692*1640*2350 |
PYD-900 | 900 | 40 | 3-13 | 15-50 | 55 | 10.9 | 2692*1640*2350 |
PYB-1200 | 1200 | 145 | 20-50 | 110-200 | 110 | 25 | 2790*1878*2844 |
PYZ-1200 | 1200 | 100 | 8-26 | 50-150 | 110 | 25 | 2790*1878*2844 |
PYD-1200 | 1200 | 50 | 3-15 | 18-105 | 110 | 25.7 | 2790*1878*2844 |
PYB-1750 | 1750 | 215 | 25-60 | 280-510 | 115-160 | 50.3 | 3910*2894*3809 |
PYZ-1750 | 1750 | 185 | 10-30 | 115-320 | 115-160 | 50.3 | 3910*2894*3809 |
PYD-1750 | 1750 | 85 | 5-15 | 75-230 | 115-160 | 50.3 | 3910*2894*3809 |
PYB-2200 | 2200 | 300 | 30-60 | 590-1000 | 260-280 | 84 | 4622*3302*4470 |
PYZ-2200 | 2200 | 235 | 10-30 | 200-580 | 260-280 | 85 | 4622*3302*4470 |
PYD-2200 | 2200 | 110 | 5-60 | 120-370 | 260-280 | 85 | 4622*3302*4470 |
5.picture show of gold ore cone breaker machine
we also have other products you may need
6.our company
Now our company domestic top ranking production equipments and precise testing instrument, each process of products is strictly inspected to guarantee the products to achieving high ex-factory standard. Besides, we cooperate with many famous universities and scientific research institutions, so that can make technical warrantee for the products in it's developing, updating and improving.
Tel:86-373-3669005 Cell:86-13569860276 Fax:86-373-3669006
Skype:xinxiangdayong01 QQ:1355135184
Welcome to visit our factory and look forward your cooperation.
