Engineers available to service machinery overseas stainless steel U shape shaftless conveyor
- 200 Set / Sets per Month
- Qingdao Shanghai
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Type: | Screw Conveyor | Material: | Other, Carbon steel |
Material Feature: | Other, screw conveyor | Structure: | Other, tube conveyor | Load Capacity: | 1.1(m³/h) |
Place of Origin: | Henan, China | Brand Name: | DY | Model Number: | GX/LS200 |
Voltage: | As your request | Power(W): | 2200 | Dimension(L*W*H): | As your request |
Certification: | ISO9001:2008 | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
ore auger conveyor machine :Wooden packing. the packing size should be according to the actual size.
Product Description
ore auger conveyor machine
1. ore auger conveyor machine usage and application
Widely applied in grain mills and feed manufacturing plants, malt houses, bulk storage systems (for cereal grains, oilseeds and derivatives), food processing facilities, fertilizer factories, and in chemical and related industries - Horizontal or inclined material conveying, distribution, collection, mixing and discharge - For floury and mealy, fine- and coarse-grained materials
2. ore auger conveyor machine features
(1).Without cleaning device at outlet, low noise, flexible arrangement on position of inlet and outlet ;
(2). Good sealing, the shell is made in seamless steel tube. The ends are connected by flange ;
(3). Working temperature is -20~50°C, with material temperature below 200°C ;
(4). Good sealing quality and rigidity. The outer casing is made of seamless steel pipes, and the end caps are connected with flanges ;
(5). Inlet trough with progressive solid-flight screw for uniform storage bin discharge ;
(6). Vessel is made of high quality seamless pipes which are connected by flange, therefore its overall rigidity is good and bearing capacity is large;
(7). When the transmission distance is no more than 30m, plate chain can be used for traction pieces;When the distance is more than 30m, it is necessary to used the plate chain to tracte
(8). This machine is a safe and reliable product, having a good air-proof performance and no leaking-out of powdery dust and can beconsidered as an ideal product of new generation for environmental protection.
3. ore auger conveyor machine principle
It works based on the principle of friction transmission.
A) High quality motor and gear box, with heavy duty design, large torqe and low noise.
B) outside tube complete with one inlet, one outlet, end flange, ball joint , inspection window.
C) standard fitting parts, middle bearing, end bearing, splined shaft coupling
D) Lifting eyes on each tube section, convinient for transport and installtion.
E) small diameter, great efficiency, high throughout rates
4.principal technical data of ore auger conveyor machine
Model | Screw Dia. (mm) | Screw Pitch (mm) | Rotation Speed(r/min) | Capacity (m³/h) |
GX/LS100 | Φ100 | 100 | 71/90/112/140 | 1.1/1.4/1.7/2.2 |
GX/LS160 | Φ160 | 160 | 50/71/90/110 | 4/6/7/10 |
GX/LS200 | Φ200 | 200 | 50/63/80/100 | 7/10/12/14 |
GX/LS250 | Φ250 | 250 | 45/56/71/90 | 13/16/20/24 |
GX/LS315 | Φ315 | 315 | 40/50/63/80 | 16/21/26/34 |
GX/LS400 | Φ400 | 355 | 36/45/56/71 | 34/41/52/64 |
GX/LS500 | Φ500 | 400 | 32/40/50/63 | 52/64/80/100 |
GX/LS630 | Φ630 | 450 | 25/32/40/50 | 80/94/116/145 |
GX/LS800 | Φ800 | 500 | 20/25/32/40 | 110/130/165/208 |
GX/LS1000 | Φ1000 | 560 | 16/20/25/32 | 150/180/230/300 |
GX/LS1250 | Φ1250 | 630 | 13/16/20/25 | 200/260/320/388 |
5.picture show of ore auger conveyor machine
