Help CenterAirtight Type Vibrating Screen for Food Industry
Related Products
-
Rotary Vibrating Separator for SeasoningsUS$ 5,880 - 7,280MOQ: 1 Set -
S49 Series Vibrator Shaker for Powdered SugarUS$ 2,000 - 8,000MOQ: 1 Set
-
Stainless Steel Vibrating Screen Separator for Pet Food With CE and SGSUS$ 1,855 - 8,000MOQ: 1 Set
-
Vibration Separator for YeastUS$ 2,000 - 8,000MOQ: 1 Set
-
Gaofu Rotary Sieving Machine With Two MotorsUS$ 4,500 - 5,000MOQ: 1 Set
Gaofu hot sale vibration sieve for food industry
Do you still worry about the product's air protection?
Choose it!
--- Airtight type vibration screen for neodymium iron boron metal powder
Enjoy the many benefits this separator can offer you
1.High capacity - Real improvements are achieved over conventional round separators in terms of increased capacity
2.Greater accuracy - Full material flow on all 4 sieve decks gives accurate grading on all meshes
3.Ease of operation and lower maintenance - The design of the vibrator housing allows for a standard motor being used rather than a vibratory type, keeping maintenance costs to a minimum
What does it do?
Check sieving of almost any wet or dry material
Remove any unwanted debris or oversize material
Filtration of liquids
How does it do it?
The material is fed onto the screen by manual or mechanical means.
All good products is vibrated through the mesh screen, any oversize material is retained on top.
The oversize can be removed by hand; vacuum cleaner or an oversize outlet can be provided.
The sieved product can be collected underneath or to the front in a tote bin, conveyed to the next process or passed into a high care area.
How does it help you?
Provides you with a quality assured, contaminant free product
Ensures you meet audit requirements for your customers
It can help to aerate product to improve mixing, conveying times
Can fit into narrow locations as low as 320mm, so no need for expensive refitting of existing lines
What else can it do?
Available in 400.600.800.1000.1200.1500.1800.2000mm diameters, it can be sized to suit your production requirements
Debagging 3 in 1 sieve station with dust extraction port to protect operators from airborne dust and provide a clean working area
Can be fitted to any convey system, connects inline on pneumatic & vacuum systems
Optional deblinding systems, both mechanical & ultrasonic.
Optional rare earth under screen magnets for ferrous material removal, this also comes with magnetic mesh
We can adapt this unit to integrate into almost any situation, no matter how improbable it seems
Application
Chocolate,Coffee,Tea,Wheat,Yeast,Spices,Sugar,Salt,Starch,Juice,Corn,Seasonings,Egg Powder,Chili powder,Coconut powder,Food additives
NOTE:
Transact certificate of origin
Authentication of invoice
Authentication of fumigation
In order to satisfy the need of different user, our company D&R the product incessantly, has developed different types product successfully and has produced excellent individual product by introducing overseas advanced producing technique. At present, in product aspect, we have two big series product of vibrating machine and sieving equipment and obtain 26 items state patents, sales quantity is up to ten thousands, deeply affirmed by all circles.
Our tenet: Honest Service Highest Quality!!!
CUSTOMIZED SOLUTIONS In addition to applying standard design options, GAOFU machines have the capability for extensive modification to meet application requirements. Such redesign is customer-driven, based on type of material, flow characteristics, capacity needs or other process parameters.
Technical parameters
Model | Effective diameter For sieving surface(mm) | Screen size | Layer | Powder(KW) | ||
Vibration motor | Common motor | |||||
GFQM-400 | 340 | 2-500 mesh | 1-5 | 0.18 | -- | |
GFQM-600 | 540 | 2-500 mesh | 1-5 | 0.25 | 0.75 | |
GFQM-800 | 730 | 2-500 mesh | 1-5 | 0.55 | 1.1 | |
GFQM-1000 | 900 | 2-500 mesh | 1-5 | 1.1 | 1.5 | |
GFQM-1200 | 1100 | 2-500 mesh | 1-5 | 1.1 | 1.5 | |
GFQM-1500 | 1400 | 2-500 mesh | 1-5 | 1.5 | 2.2 | |
GFQM-1800 | 1700 | 2-500 mesh | 1-5 | 4 | 3.0 | |
GFQM-2000 | 1886 | 2-500 mesh | 1-5 | 4 | 3.0 | |
