Specifications
a. High sieving accuracy for raw material in food dustryb. CE & ISO 9001:2008
c. Food-grade standard
e. Simple operation
Rotary Vibrating Separator
ABOUT US
Company Name |
Xinxiang Gaofu Sieving Machinery Co., Ltd. |
Country/Territory |
China (Mainland) |
Type |
manufacturer |
Year Established |
2000 |
Legal Form |
Limited Liability Company (Invested Or Controlled By Natural Persons) |
Registered Capital |
RMB 10,600,000 |
company profile |
Our company is specialized in producing vibrating screen or sieving machine, has advanced manufacture equipment, abundant technology power, complete testing measures, strict management system and favorable corporation credit-standing. We have assessed a high & new technique corporation by He Nan since & Technology department and regard as observing contract and stressing honor corporation by Xinxiang City. Our products have granted the glory titles of the Qualified Good Product in the State Supervision and Spot-checking, the State Quality Trusted Product, and Consumer-satisfied Corporation in State Quality Service and Stable Qualified Product in the State Quality Inspection. Our company first passed CE Certification and ISO9001: 2000 International Quality Management System Authentication. |
About S49 series vibrating separator
Brand Name |
Gaofu |
Model |
S49 |
Type |
Vibrating Screen |
Condition |
New |
warranty period |
1year |
Screen |
From 1 to 4 layers |
Application Fields |
Food industry, chemical industry, powder, particles, medicine industry, metal powder |
Screening Materials |
Food powder and particles |
Certification |
ISO9001:2008, CE |
Colour |
According the customer’s requirement |
[Introduction]
Gaofu S49-A series rotary vibrating separator is one kind of high appreciated sieving machine for food industry, it is designed for accurate screening of wet and dry raw materials. It can up to five different fractions in one-time screening process.
[Principle of the structure]
S49-A series rotary vibrating separator use upright motor as the source of vibration, These consist of specially designed motor which is mounted vertically at the center of the base plate of the screen.Equipped eccentricity hammer on the both sides of motor,change circumrotate to level, upright and incline movement, then pass these three movement to the surface of the screen. Adjust the phasic angle on the both sides of the top and bottom to change the movement orbits of the surface screen.
[Features]
a. Any powders and mucilage are suitable for screening;
b. Easily to replace the screen, only 3-5 mins to replace the screen;
c. Never jam the hole meshwork, no powder flying;
d. Discharge the impurity and coarse materials automobile and operates continuously;
e. Unique- designed screen flame type, simple operation and convenience washing, long duration of screen;
f. Low noise;
g. High screening accuracy.
Food-grade Rotary Vibrating Screen:
Input
Free spare parts list
More Vibrating Screens Technical parameters
Note:
1. Each type can be 1-5 layers (But 3 lagers are suggested), and the mesh is from 5 to 500 meshes;
2. Material: Q235A / SUS 304 / 316L;
3. Voltage: 220 / 380V /415V / 440V, Frequency: 50 / 60 HZ;
4. If the specification or appearance has changed, we will not notify additionally.
What did you think of our factories?
== Product gallery ==
== Workshop ==
