DZ-800 Large Capacity Flour Vibrating Screen

Flour rotary vibratory inpurity machine

 If you are still concerns in your products for the filtration problems,  please click on me, and I will you recommended a filter sieve for you, to help you solve your problem of filtering;

Let us know more about China flour vibrating screen as follows:

Using scope

Rotary screen is also mainly used to sieve particles or powder precisely/roughly in the industry of bread  flour,starch,laundry powder,metal powder,chemical additive,non-ore,etc.

Working principal

1.Turning on the vibration motor,centrifugal effect produced by the Eccentric block generate spin-based quantiative movement in the horizontal direction,so materials will be vibrated and screened.

2. Adjust exciting force to change discharge capacity according to production demand.

Features

1. Simple structure,easy to operate, large processing capacity, long service life, high productivity, low power consumption, easy installation.
2. Processing materials quickly, even materials will not be piled up, rapid screening of materials, obvious effect.
3. Can be directly installed between the raw materials barrel and the storage drums, easy to install, also save space.
4. IP54 protection rank, F level insulation, though work 24 hours a day can greatly extend the vibration motor’s using life; motor still can run in the bad environment.

  Description

DZ series vibration sieveis a new-type screening machine, using a single horizontal vibration motor, discharges the materials directly, having a greater handling capacity. It is used in screening granules and powders of flour, starch, detergent, metal powder, additive, chemicals, non-mining industries etc. roughly, precisely. All products contact parts are made of stainless steel, elegant design and durable, small dimension, save space and easy to move.

Automation, the 24 hours of continuous production.

   Design of ultra-low-mute, Seal stringent, liquid does not leak; the powder will never be soared. It is easy to clean up the internal and external, non-health corner, meeting with food-grade GMP standards.

Function of vibrating sieve machine:

1. Classification

Each of our products can screen and separate precisely and continuously, the Multi-layer type can screen and separate five groups of different particles at a time. It is suitable for dry materials.

2. Filtrating

The mixture of solid and liquid can be separated effectively by single or multi-layer type into different grade materials.

3. Remove the impurities

Our equipment can quickly separate a few oversize or undersize particles from a quantity of materials.

    Daily maintenance:

1. before running

   (1) To check coarse mesh and fine mesh if there is damage

   (2) Each group clamps is locking.

2. Running

   (1) Notice any abnormal noises

   (2) Electric current is stable

   (3) Whether the vibration is abnormal.

3. after running

   (1) After used clean up the vibration every time

   (2) To inspect regularly the coarse mesh, fine mesh and the spring if there are fatigue and damage

   (3) Whether each part of the vibrating body caused damage due to vibration.

   (4) Need to add the site to be the lubricating oil

Technical parameters

Note:

1. Material: SUS 304 / Q235A / 316 L.

2. Voltage: 380V /400V.

3. Voltage: 380V /400V, Frequency:50 / 60 HZ.

4. If the specification or appearance has changed, we will not notify additionally.
