Direct Discharge Vibroscreen

Direct Discharge Vibroscreen photo-1
US$ 400 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
Gaofu
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name Gaofu
Model Number SZS-1500-1S
Usage Sugar
Type Other, Vibrating screen
Voltage 220V.380V.415V
Power(W) 1.1 KW * 2 SETS
Weight 900 KG
Dimension(L*W*H) 2700*1630*1170mm
Certification CE ISO 9001: 2008
Warranty 12 month
After-sales Service Provided Overseas service center available

 direct discharge vibroscreen

1. Operating principle



SZS series vibrating screen have two vibration sources. The two horizontal vibration motors on both sides of the vibrating screen serve as the vibration sources. After entering into the vibrating screen, under the force of the vibration source, material would move along a certain path on the surface of the screen meshes. While moving at high speed in a back and forth way, the material are being stripped, broken and recombined by the vibration force, so that they could be filtered quickly, those that could not be filtered would be discharged out through the discharge hole. This completes the screening process.







2. Structure of the screening device



See the following chart. Screen meshes, supporting frames and hoppers in all types of our products are made of austenitic stainless steel( 304, 316) and other components are made of ether austenitic stainless steel( 304, 316) or plain carbon steel. The device is circular in shape. The electrical motors are installed on both sides of the device. The discharge hole could be rotated 360°.





No.

Type

Power

kW

Motor Speed

r/min

Sieving Area

/m2

Weight/kg

1

SZS -600

2×0.18

1450

0.23

140

2

SZS -800

2×0.25

1450

0.42

220

3

SZS -1000

2×0.25

1450

0.64

250

4

SZS -1200

2×0.55

1450

0.95

430

5

SZS-1500

2×0.75

1450

1.61

945





  direct discharge vibroscreen



direct discharge vibroscreen
