GAOFU Full-closed type vibratory linear feeder
I Brief Introduction
1. Vibratory linear feeder is a new feeding equipment, which is widely used in metallurgy, coal, chemical, building materials, ceramics, grinding, food and other industrial and mining industries.
2. Classification: we mainly provide the following types of vibrating feeder.
♦ Suspension installation: open type and closed type
♦ Pedestal installation: closed type
3. Stucture ( Full-closed type vibratory linear feeder with suspension installation)
It mainly consists of four parts, feeing trough, vibration body, vibration motor and damping device.
Driving the vibration motors, it engenders a specific exciting force, which drives vibration frame to make periodic linear and reciprocal vibration along the inclined direction. When the vibration accelerated speed of vertical component of vibrating frame is larger than gravity accelerated speed, materials are throwed up and move forward along aparabolic path; throwing up and falling down are completed in a flash.
III Application Scope
1. You can feed massive, granular, powder materials from sorage silos to affected devices uniformly, quantitatively and continuously, such as belt conveyor, vibrating conveyor, bucket elevator, crusher, vibrating screen, grinder.
2. It adapted for automatic batching, quantitative packaging and automatic control.
V Main Features
1. Feeding capacity is adjustable
2. Small volume, light weight, simple structure
3. Easy installation and convenient maintenance
4. Low service life of feeding trough
5. Flow stability, low noise and small power consumption
V Technical Parameters ( Full-closed type vibrating feeder with suspension installation)
Model |
Max input size(mm) |
capacity |
motor power |
Installaition Slope |
weight |
Size of Funnel |
GZD-180×80 |
300 |
30-80 |
2×1.5 |
0-10 |
0.8 |
1800×800 |
GZD-300×90 |
500 |
40-100 |
2×2.2 |
0-10 |
1.5 |
3000×900 |
ZSW-380×96 |
500 |
90-100 |
11 |
0° |
3.98 |
3800×960 |
ZSW-490×96 |
500 |
120-240 |
15 |
0° |
5.5 |
4900×960 |
ZSW-490×110 |
580 |
120-280 |
15 |
0° |
5.72 |
4900×1100 |
ZSW-590×110 |
600 |
280-500 |
22 |
0° |
6.13 |
5900×1100 |
Note: This specification is just for reference, any changes are subject to the products.
GAOFU company have a perfect after-sales service system and professional technology team to provide customers with prompt and thorough service. Our price are most competitive and reasonable, all order will be supplied within the stipulated period. Awaiting your first inquiry order
