Industrial Microwave
Technical Data Sheet Reference
Model |
BDMD-M-T-6 |
BDMD-M-T-9 |
BDMD-M-T-15 |
BDMD-M-T-18 |
Microwave frequency |
2450±50 MHz |
|||
Input voltage |
3PH AC |
|||
Food, Pharmaceutical, Cosmetic and Chemical industry for the drying of heat sensitive products or products sensitive to oxidation.
Drying of thick product with low thermal conductivity.
Low temperature drying of fruits, vegetables, meats.
Advantages:
Continuous or Batch operation
Volumetric drying or heating
Immediately regulation capability
The energetic conversion of the microwaves into heat takes place directly in the product.
The resulting steam pressure ensures rapid and direct outlet of the water from the product.
Microwave power |
6Kw (Adjustable) |
9Kw(Adjustable) |
15Kw (Adjustable) |
18Kw (Adjustable) |
Input power |
≤7Kw |
≤10Kw |
≤17Kw |
≤20Kw |
Chamber color |
Silver-white |
Chamber material |
Industrial stainless steel-food grade |
Number of layers |
1~3 |
Microwave leakage limit(mW /cm2) |
≤3 |
Working temperature(℃) |
60-120 (Adjustable) |
Cooling method |
Water-cooling or Air-cooling |
Weight(Kg) |
550 |
600 |
850 |
1350 |
Chamber size |
1.2*1.0*1.6m |
1.4*1*1.6m |
1.9*1.5*1.8m |
2.4*2*1.8m |
Installation area |
3.0*2.0*2.5m |
3.0*2.0*2.5m |
4*2.5*2.5m |
4*3*2.5m |
Ambient temperature(℃) |
-10 ~ 40 |
|||||||||||||||||||||
