Industrial Conveyor Belt Type Microwave Oven
Technology Parameters
Model | Working Frequency (MHZ) | Output power (kw) | Microwave leakage (mW/cm2)
| External Dimension (m) | Installation Area (m) | Gross Weight (Kg) | Container Quantity |
BDMD-CH-P-50 | 2450±50 | 50 | ≤1 | 10x1.5x1.8 | 12x4.0x2.5 | 3200 | 1x20GP |
BDMD-CH-P-80 | 2450±50 | 80 | ≤1 | 13x1.5x1.8 | 15x4.0x2.5 | 5000 | 2X20GP |
BDMD-CH-P-100 | 2450±50 | 100 | ≤1 | 15x1.5x1.8 | 17x4.0x2.5 | 6000 | 3X20GP |
BDMD-CH-P-130 | 2450±50 | 130 | ≤1 | 18x1.5x1.8 | 20x4.0x2.5 | 7000 | 3X20GP |
BDMD-CH-P-160 | 2450±50 | 160 | ≤1 | 21x1.5x1.8 | 23x4.0x2.5 | 8000 | 4X20GP |
Remark: All technology parameters are subject to user manual, some parameters will be changed according to customer’s demand.
Example of use:
Food, Pharmaceutical, Cosmetic and Chemical industry for the drying of heat sensitive products or products sensitive to oxidation.
Drying of thick product with low thermal conductivity.
Low temperature drying of fruits, vegetables, meats.
1. Working power: Voltage 380V, Frequency 50HZ.
2. Patent core components manufactured by BODA, reliable and stable performance.
3. Whole machine chamber are made with anti-corrosion stainless steel, with smooth appearance and easy for cleaning.
4. Interface operation and on-site monitoring, PLC auto-control system, all the datum can be saved, output and printed etc.
5. Working parameters can be seted easily according to different drying demand according to different materials.
6. Microwave power stepless adjustable, conveyor speed adjustable, temperature and humidity are intelligent controled.
7. Machine start, power off automatically, drying material and microwave generator can start and off synchronously.
8. Adopting Non-contact infrared measuring temperature technology, ensure the accuracy of temperature control easily.
9. Material loading and unloading operated easily, easy for connecting to other process, can achieve automation flow operation easily.
10. BODA unique ventilation system can speed up moisture removal speed, raise drying efficiency.
11. Conveyor material is teflon, which can resist high temperature to 300 celcius.
12. Conveyor auto deviation-checking device can keep the machine running smoothly and steadily.
