3 ton beam lifting plain trolley with trade assurance
- 10000 Unit / Units per Month
- QINGDAO
- T/T Credit Card
- Hand tool parts castings
- OEM/ODM steel air tool parts / needle bar bushing
- air chuck,air accessory,pneumatic tool parts
- Air conditioner parts develop stamping tooling die
- Investment Casting Pneumatic tools accessories with Stainless Steel and Alloy Steel Materials
- customized high quality Milling Tools
Product Details
Place of Origin: | Shandong, China | Brand Name: | JNDO | Model Number: | GCT |
Product Description
3 ton beam lifting plain trolley with trade assurance
1.Plain trolley should be formed a complete set with chain hoist or other lifting machines.
2.There are ball bearings are in layed in the wheels of the geared trolley.
3.The geared trolley is a lifting machine that has high efficiency in operation with small hand-pull/push force.
4.Geared trolley should be fit on the bottom flange of I-beam to compose a running lifting trolley.
Precaution of plain trolley:
1.Overloading is strictly prohibited.
2.While lifting the load,passing or working under the lifting load is strictly prohibited.
3.Stop operating immediately and fix a breakdown in case the pull force exceeds that of normal operation or there troubles.
4.Bearing ,gear,etc should be greased regularly and examine the fasteners to make sure that are tightened.
Specifications of plain trolley:
Model | Capacity (T) | Test load (T) | Min.radius of curve | Dimensions (mm) | I-steel available (mm) | Net.WT.(KG) | |||||
A | B | C | H | F | |||||||
GCT 0.5 | 0.5 | 0.753 | 0.9 | 242.5 | 170 | 187 | 105 | ≈3 | 68-94 | 4.8 | |
GCT 1 | 1 | 1.471 | 1 | 245 | 206 | 206 | 109 | ≈3 | 68-100 | 7.7 | |
GCT 1.5 | 1.5 | 2.206 | 1 | 279.5 | 228 | 236 | 125 | ≈3 | 88-118 | 12.8 | |
GCT 2 | 2 | 2.942 | 1.1 | 179.5 | 240 | 243 | 133 | ≈3 | 94-124 | 12.8 | |
GCT 3 | 3 | 4.413 | 1.3 | 344 | 282 | 321 | 179 | ≈3 | 116-140 | 34.5 | |
GCT 5 | 5 | 6.129 | 1.4 | 362 | 327 | 393 | 220 | ≈3 | 142-180 | 43 | |
GCT 10 | 10 | 12.258 | 1.7 | 402 | 389 | 490 | 275 | ≈3 | 142-180 |
