Specifications
The line shall be used to produce single wall corrugation pipe in PVC, PP and PE raw Material.
Features:
1) Adopts lastest German technology, and it is convenient to change the mould block,
Then it is easy the change the size of produced pipe
2) The line shall be used to produce single wall corrugation pipe in PVC, PP and PE raw
Material
3) Moulding corrugated pipe with smooth inside and outside surface, and even ripple
At one time by corresponding die
4) Used as wire and cable passing pipe, washing machine drain pipe,
Dust collector pipe and ventiduct
5) Small size corrugation pipe of 4mm - 6.7mm are used in car.
(plastic pipe production line, pe/pvc corrugated pipe extrusion line, pe/pvc pipe making machine,
plastic extruder
Composition of the production line |
Size |
Power(kg) |
Weight (kg) |
Set |
Characteristics |
Singal screw extruder |
SJ65/28 |
22 |
2500 |
1 |
High efficient extruding |
Machine head |
|
|
|
1 |
Compelete cooling system |
Flat corrugated pipe profiling machine |
BW-1 |
2.2 |
3000 |
1 |
Can produce 2-flat,3flat,4-flat,5-flatpipes |
Cooling spray water channel |
6 M |
Pump power 4kw |
100 |
1 |
Strong spray cooling system |
Automatic cutting machine |
STYF-100 |
2.2 |
200 |
1 |
Micro computer control ,automatic fixed length cutting |
Mould cooler |
SML-3F |
3 MP |
180 |
1 |
Rapid cooling mould |
Funnel type drying machine |
TG-U40 |
2.6 |
50 |
1 |
It is fixed on the main mchine and can avoid getting wet of twice |
Automatic feeding machine |
ZJ-200 |
1.1 |
50 |
1 |
Automatic feeding |
Plastic mixing machine |
SH50 |
1.1 |
80 |
1 |
Mixing &coloring of raw material |
