Specifications
1. truck-mounted drilling rig2. rotary drilling rig
3. high drilling efficient rig
4. easy operation drilling rig
HFT350B Truck-mounted Drilling Rig
Main Features:
1. it adopts truck mounted and directional circulation rotary drilling method.
2. 6X4 special crane chassis of brand SINOTRUK, transmit, power, gearbox, mud pump and other accessories are set up on the chassis, very compact structure.
3. truck engine provides power for drilling rig, the rig setups distribute implement and hydraulic system.
4. the adding pressure device is hydraulic, thus it has a high efficiency when the rig drill through mud rock and weathering formation by using the adding pressure implement.
5. the master driving of rig is mechanical, the four jacks and mast are hydraulic operated. Distribute box, sewage pump, master driving clutch system are air operated.
Technical Parameter:
Drilling depth(M) | 80 | 300 | ||
Drilling diameter(mm) | 1500 | 500 | ||
Speed of turntable(r/min) | 21.2, 36, 63.2, 100.6, 155, 20.2(reverse) | |||
Torque of turntable(KN.m) | 18, 10.6, 6, 3.8, 2.5, 18.9(reverse) | |||
Single rope lifting capacity of windlass(KN) | 30 | |||
the max torque of whole machine(KN.m) | 40.55 | |||
The lifting capacity of hook(KN) | 180 | |||
Bearing capacity of mast (KN) | 180 | |||
The height of mast (mm) | 11500 | |||
Bearing capacity (t) | 25 | |||
Pipe | Kelly (mm) | 108×108×7500 | ||
Assistant pipe (mm) | 89(diameter)×10×5500 | |||
Hydraulic pump | Model | CB-HP50/32Z | ||
Pump delivery (ml/r) | 50/32 | |||
Rated speed (r/min) | 3500-3700 | |||
Rated pressure(MPa) | 20 | |||
BW850/2A plunger pump
| Diameter of cylinder (mm) | 150 | ||
Stroke of piston (mm) | 180 | |||
Theory of flow (L / min) | 600 850 | |||
Rated pressure (Mpa) | 3 2 | |||
Pounding times (min-1) | 58 82 | |||
Diameter of suction tube (mm) | 127 | |||
Diameter of drain pipe (mm) | 64 | |||
Input speed (r / min) | 470 | |||
Input power (kw) | 40 | |||
Overall dimensions (mm) | 2000*1030*1400 | |||
Weight (t) | 1.5 | |||
Truck chassis | Model | TAZ5191TXJ | ||
Drive form | 6×4 | |||
Engine | Model | TBD226B-6 | ||
Rated power(KW) | 132 | |||
Speed (r/min) | 2300 | |||
Size (L*W*H)(mm) | 11110×2490×2500 | |||
The best working gear (or speed) | 5th gear(1000-1400r/min) | |||
The highest speed(Km/h) | 75 | |||
Weight (kg) | 19340 | |||
Transport size(L*W*H)(mm) | 12160*2490*3440 | |||
Working size(L*W*H)(mm) | 11110*2490*13110 | |||
