Specifications
portableeconomical water well drilling rig HF801.full automatic, 2 persons can operate
2.small volume&light weight
Portable and practical drilling rig HF80 for water well
I. Application
This machine mainly used to farm irrigation, garden irrigation, and water well drilling, etc.
It can drill 60-80m depth, and drilling diameter is 70-300mm. It can apply to different stratum, such as sand, soil, clay, gravel and so on.
II. Features and Advantages
1. Light weight. The main engine is only 135 kg.
2. Easy to operate. Needing little experience to operate.
3. Durable. The first generation of products used for 13 years, drilled more than 4000 water wells,
nearly no repair record except the drilling bits.
4. Carbide tipped drill. Can drill through hard stratum, except for thick rock layer.
5. Reducing labor intensity. Equipped with lifting mechanism.
6. High efficiency. In plain area, the drilling speed could reach 20 meters depth per hour.
7. Economical. It can be called the most economical water well drilling machine.
III. Main Technical Parameter
Drilling depth | 30-80m |
Drilling diameter | 70-300mm |
Power Engine | 12HP |
Overall dimension of the main engine (LxWxH) | 1100X600X500mm |
Weight (main engine) | 135kg |
