Specifications
HF300 large diameter foundation drilling rig1.300m depth
2.500m large diameter
3.multifunction
4.easy to operate
HF300 large diameter foundation drilling rig
Main feature and Application
1 ,HF300 engineering, water well drilling rig can use with 108mm and 89mm diameter drilling pipe.
2, it adopts mechanical drive,turn table type structure
3, it adopts small gantry trailer type ,up frame by itself , so it is convenient for far distance construction
4, the main components of thei drilling machine, such as hoist,turntable,gear box,tower etc all are made by our factory,reliable performance ,quality guarantee
5,it’s suitable for construction of high-rise building,bridges,geology mine,ports,darm foundations,water well drilling and so on
6,it’s easy to operate,stronger usability ,convenience to maintain ,small investment,effects fast ,it’s the best choose of users
Technical parameters | |
Drilling depth (m) |
300 |
Drilling diameter (mm) |
500 |
Inner diameter of turntable (mm) |
340 |
Turntable rotation speed( forward and reverse) (r/min) |
36, 52 |
Rated output torque of turntable (KN.m) |
10 |
Hoist lifting capacity (single rope) (KN) |
30 |
Bearing capacity of hydrant (KN) |
150 |
Matching power of main machine (KW) |
22 |
Working condition (mm) |
6000×2400×9000 |
Transport condition (mm) |
8550×2400×2775 |
Weight of whole machine (kg) |
3210 |
