High Quality,for High Building,port and Bridge!!!KP3500 Full Hydraulic Pressure Rotary Mode Drilling Machine

High Quality,for High Building,port and Bridge!!!KP3500 Full Hydraulic Pressure Rotary Mode Drilling Machine photo-1
US$ 442,000 - 472,416 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other
Place of Origin:
Henan, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai as per the client
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other
Place of Origin Henan, China
Brand Name HF
Model Number KP-3500
Usage Other

Specifications

KP3500 Full Hydraulic Pressure Rotary Mode Drilling Machine
1,Shallow well with heavy caliber
2,good stability
3,convennient

KP3500 Full Hydraulic Pressure Rotary Mode Drilling Machine

 Product description:



The machine is circumgyration drilling machine that the rotary drives drilling tool to bore by ratation, adopts full hydraulic pressure drive, oil sylinder disappearing and bumper, electrohyaulic combined control, steel wheel traveling and disassembly transport. The machine can adopt positive and nagative circulation and other deep drilling technique, adapt to various stratum. It is preferred equipment for foundation constrution of river’s bridge and dock, and also adapts to large diameter borehole construchtion such as sewage well. It takes great efforts in many bridges foundation construction of Changjiang River.



 High quality,for high building,port and bridge!!!KP3500 Full Hydraulic Pressure Rotary Mode Drilling Machine

The machine wins the first prize of Scientific and Technical Advance in Henan Province and Zhengzhou City, the second prize of Scientific and Technical Advance of Construction Ministry and National New Product Prize in 1996 through the authentication of ministry grade, and obtions national parent. The main technical indexes is in leading position in domestic same species.



Main Technical Parameter





Drilling Diameter(m)

Rock stratum 3.5

Drilling Depth(m)

120

Max.Torque(kN.m)

210

Rotary Speed(r/m)

0~24

Max. Lifting Capability(kN)

1200

Max.Pull Down Force(kN)

600

Oil Pressure(Mpa)

18

Diameter Of Drilling Rod(mm)

275

Main Motor Power(kW)

30×4

Aux. Motor Power(kW)

3

Lifting Power(kW)

75

Main Machine Weight(t)

47

Size (L×W×H)(m)

7.1×6.4×8.7
