Hydraulic Rotary Drill Machine HF115Y-type Crawler Hydraulic Drilling Rig

Zhengzhou Han Fa Imp & Exp Trading Co., Ltd.
Hydraulic Rotary Drill Machine HF115Y-type Crawler Hydraulic Drilling Rig thumbnail-1
Hydraulic Rotary Drill Machine HF115Y-type Crawler Hydraulic Drilling Rig photo-1
US$ 20,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rotary Drilling Rig
Power Type Diesel
Place of Origin Henan, China
Brand Name HF
Model Number HF115Y
Usage Other, DTH
Dimension(L*W*H) 5270*1950*2300
Weight 4170Kg
Certification ISO9001
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

hydraulic rotary drill machine HF115Y-type crawler hydraulic drilling rig
2, drill 90-130mm ,30-40m depth
3. high efficiency;



                                         Hydraulic rotary drill machine

HF115Y-type crawler hydraulic drilling rig




hydraulic rotary drill machine HF115Y-type crawler hydraulic drilling righydraulic rotary drill machine HF115Y-type crawler hydraulic drilling rig



1.Advantages---HF115Y Hydraulic movable drill



  1. High efficiency,
  2. crawler type, high speed
  3. large torch
  4. low air comsumption
  5. slide-skid ensures the stability

 2. Main technicla parameters of HF115Y:





Bore diameter

90-130mm



Bore depth

40m



Walk speed

0-2.5kw/h



For rock

F=6-20



Air pressure

0.7-1.6Mpa



Air consumption

7-15m³/min



Once promotion

3000mm



Skid pitch

100°



Swinging angle of skid

Left and right total 70°



Rotation speed

0-120r/min



Host power

45Kw





Climb ability

35°



Dimension(L*W*H)

5270*1950*2300(mm)



weight

4170Kg





3. About us :

hydraulic rotary drill machine HF115Y-type crawler hydraulic drilling rig



hydraulic rotary drill machine HF115Y-type crawler hydraulic drilling rig
