Specifications
HF100YA2 air drilling machine1.crawler type,easy move
2.hydraulic,easy move
3.depth 30m,dia.90~130mm
4.for rock layer drill
crawler type, hydraulic HF100YA2 air drilling machine, can drill depth up to 30m
Main feature
HF100YA2 crawler hydraulic drilling rig, using a new hydraulic technology, with low air consumption
rotary torque, variable-bit-shift convenient hole
the drilling rig structure compact, the smallest turning radius of only 2.8m, while promoting a retractable
sliding shelf compensation, drilling hole when the sliding frame support on the ground, drilling and
good stability.
The drilling rig is mainly suitable for open mining, water conservancy, power plants, road building and
other Rock drilling blasting holes.
Technical parameter
Total Weight(kg) | 2800 |
Drilling diameter(mm) | 90~130 |
Dimension (L * W * H) (mm) | 4100*2030*2020 |
Drilling depth (m) | 30 (max:40) |
Traveling speed(km/h) | 2 |
Once promotion distance(mm) | 2000 |
Grade ability(°) | 30 |
Working pressure(mpa) | 0.7~1.4 |
Chassis ground clearance(mm) | 260 |
Air consumption(m³/min) | 7~15 |
Skid pitch(°) | up and down total 100 |
Host Power(kw) | 33 |
Sliding tilt swing(°) | Left 35, right 10 |
For rock(f) | 6--20 |
Skid compensation(mm) | 900 |
Impact frequency(r/min) | 840 |
