Coal Mining Drilling Rigs HF138Y Crawler Type Hydraulic Borehole Drillling Equipment With Air Compressor

Zhengzhou Han Fa Imp & Exp Trading Co., Ltd.

US$ 24,000 - 75,050 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Rotary Drilling Rig

Power Type:

Diesel

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Rotary Drilling Rig

Power Type Diesel

Place of Origin Henan, China

Brand Name HF

Model Number HF138Y

Dimension(L*W*H) 5200*2030*2300mm

Certification ISO9001

Warranty ISO9001

Specifications

coal mining drilling rigs HF138Y Crawler type Hydraulic borehole drillling equipment
1,use with air compressor

coal mining drilling rigs HF138Y Crawler type Hydraulic borehole drillling equipment

1.Advantages---HF138Y Hydraulic movable drill

2. Main technicla parameters of HF138Y:

Main technical parameters of HF138Y
Wind pressure (Mpa)	0.7----1.6
Air consumption (m³/min)	10----15
Drilling diameter (mm)	90----130((max:203)
Drilling depth (m)	level 40m,down 80m
Once promotion distance (mm)	3000
Drill diameter (mm)	60
Skid compensation (mm)	900
Maximum lift force (N)	24900
Skid pitch (°)	up and down total 95
Swinging angle of skid (°)	Left 38, right 31
Boom Pitch (°)	up and down total 70
Boom swing angle (°)	Left 41, right 33
Grade ability (°)	30
Chassis ground clearance (mm)	260
Travelling speed (km/h)	2
Back to the transit speed (r/min)	0----80
Rotary torque (N.m)	2000
Host Power (Kw)	45
For rock (f)	6----20
Impact frequency (r/min)	950---1500
Total Weight (kg)	3800
Dimension (L * W * H)	520020302300
The drilling rig is mainly suitable for open mining, water conservancy, power plants, road building and other Rock blasting hole drilling
