MSW sorting and recycling plant

                     Shredder Machine /Crusher Machine

HC solid waste shredders are used to shred municipal solid waste, bulky waste, industrial waste, bottle waste,special hazardous waste, medical waste, food waste, electronic waste, waste of paper mill, biomass, waste tires etc. It reduces the dimensions of waste through cutting, breaking and tearing, even hard to shred wastes, such as carpets, mattresses and plastics etc. can be easily shredded.

HC solid waste shredder mainly includes double shafts cutters group, shell, gearbox, reducer, motor, PLC cabinet, input hopper and equipped with installation frame and other accessories to insure working reliably.

Controlled by PLC, the power from the motor buffered by the reducer actuates the driving shaft. Then the driving shaft actuates the driven shaft so that two groups of cutters equipped in the driving shaft and the driven shaft rotate in opposite directions to shred solid waste.

Solid waste shredder crushes various kinds of solid waste like rag, glass, paper,

wood, articles for daily use, empty can, residues, small pieces of brick, rubber products, string,

hose, leather products, plastic products supplied evenly from conveyor directly to ≤20mm

small particles. All components of the horizontal type crusher are designed to meet working 24

hours continuously and achieve the longest service life in the worst environment.

 Product Detail:

1. Low speed, high torque, low noise, high throughput
2. Wide range of applications, excellent cutting performance
3. Sturdy, Wear-resistant, Reliable, Long lifetime
4. Renewable cutters with harden alloy steel
5. Patented bearing sealing system
6. Overload protection, Reversible rotary
7. Siemens motor, PLC control automatically
8. Less downtime, low operation cost, easy maintenance
9. Customized shredding solution

10. Double shafts design, working continuously. Cutters and gaskets are separable, not overlay by some pieces of cutters together or integral one.

11. The cutters & gaskets are made of alloy steel 4130 with surface harden evenly with hardness not less than 45~50HRC.



  Company Profile

       Xiamen Huanchuang Water Industry Co.,Ltd. is a high-tech enterprise located in Torch Software building in Xiamen Software Park II. Our company is specializing in R&D and production of wastewater grinders,solid waste shredders. We are the first company which designs, produces the wastewater grinders and  solid waste shredders in china and the only exporting company of wastewater grinders and  solid waste shredders . After absorption and innovative improvement, we have designed the solid waste shredder,wastewater grinders with own intellectual property rights and dozens of patents.Our technology has achieved advanced level in this industry and has been leading in China.Our wastewater grinders,solid waste shredders&crushers have been used widely in hundreds of cases in the industries of wastewater treatment, municipal water supply and drainage, solid waste reduction,wastes to energy etc. and have been highly recognized by our customers.

      Our company has achieved ISO9001 quality system.We survive with high quality, develop with excellent service and aim to be the NO.1 brand of grinding and shredder equipments.We win the market with our strong ability and maintain good relationship with customers through our service.

       Our Philosophy: Focus on environment, technology innovation. Our Quality Guidelines: Customer-centered, innovative development,zero defect. Our Goal: Create maximum value for customers.

       We will supply high quality and comprehensive service to cooperate and develop together with our customers.

Certification

Service

    Top quality and competitive price,the goods are directly selling from our own factory.

     The customer is the foundation of our enteprise.We attach great importance to dialogue with you to know more about your specific working requirements and find suitable shredder for you ,no matter standardized or customized solution is needed,so that you can benefit from our best shredding technology.

       If you want to know more details,welcome to visit our website:  , and contact me. Your inquiry are warmly welcomed and will be replied in 24 hours.Hope can develop win-win business.
