Home > Products > Crusher plant > Durable 250x400 Jaw Crusher

Durable 250x400 Jaw Crusher

FOB Price

US$ 235 - 98,999 / Set

1 Set(Min. Order)

Port Lianyungang port Qingdao port .
Payment TermsT/T L/C D/P D/A Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, Jaw Crusher, Jaw Cusher Drawing,Mine Equipment
Application	mining, Breaking ore stone and rock	Motor Type	AC Motor
Capacity(t/h)	1mt/h-220mt/h	Place of Origin	Henan, China
Brand Name	Xinguang	Model Number	PE750
Certification	ISO	Warranty	1 year
After-sales Service Provided	Overseas service center available

Product Description

Durable 250x400 jaw crusher

Jaw Crusher is a kind of crude crushing equipment widely used at home and abroad. It mainly applies for primary and crude crushing of all kinds of hard rocks and block materials . Large and medium-sized jaw crushers are the leading products of our company .

The motor drives the belt wheel ,and makes movable jaw up and down by eccentric shaft. When the movable jaw rises , the angle between the fixed jaw and movable jaw gets larger , and the materials can be crushed to reach the crushing target. When the movable jaw is down , the angle between the fixed jaw and movable jaw becomes smaller. The movable jaw plate leaves the fixed jaw plate under the function of drawbar and spring , and then the crushed materials are discharged from the lower outlet of the crushing cavity.

Technical Parameter

model	specification	Size of the feeder opening L×W(mm)		Max feeding size (mm)	Adjusted range of output (mm)	Capacity(t/h)	Spindle speed (r/min)	motor		Weight (t)
model	specification	Size of the feeder opening L×W(mm)		Max feeding size (mm)	Adjusted range of output (mm)	Capacity(t/h)	Spindle speed (r/min)	Model	Power (km)	Weight (t)
PE-150	150×250	250	150	125	15-45	1-4	285	Y2-132S-4	5.5	1000
PE-200	200×300	300	200	180	20-70	2-8	250	Y2-160M-4	11	1500
PE-250	250×400	400	250	210	20-80	5-20	280-320	Y2-180L-6	15	3000
PE-400	400×600	600	400	350	40-100	25-64	250	Y2-250M-8	30	6800
PE-500	500×750	750	500	425	50-100	45-75	280	Y2-280M-6	55	12500
PE-600	600×900	900	600	500	72-160	56-192	250	JR117-8	80	16800
PE-750	750×1060	1060	750	630	80-140	80-220	250	YR315S-8	90	2700
PEX-150	150×750	1000	150	120	10-40	8-35	300	Y2-180L-6	15	3500
PEX-250	250×750	750	250	210	15-50	15-45	320	Y2-280S-8	37	6350
PEX-250	250×1000	750	250	210	15-50	13-35	300	Y2-250M-8	30	6010
PEX-250	250×1200	1200	250	210	15-50	20-60	320	J2-280M-8	4	7700
PEX-300	300×1300	1300	300	250	20-90	20-95	300	Y2-315M-8	75	11302
