Home > Products > Crusher plant > High standards of quality famous jaw crusher
High standards of quality famous jaw crusher
- 60 Set / Sets per Month
- Tianjin Shanghai Qingdao or China main ports
- T/T L/C D/P D/A Credit Card PayPal
- Tertiary Reversible Impact Hammer Crusher with High Chrome Blow Bar
- China Wheat and Grain Transport Vibrating Feeder Price in Shanghai
- Good Quality Heavy Hammer Crusher for Crushing All Kinds of Ores
- Sand Ore and Coal Vibrating Feeder Machinery Used in Mining Industry
- High Efficiency Stone Crushing Plant Impact Stone Crusher
- Sound Equipment Impact Crusher Machine for Stone Crushing Line
Product Details
Condition: | New | Type: | Jaw Crusher | Application: | mining, Ore |
Motor Type: | AC Motor | Capacity(t/h): | 220 | Place of Origin: | Henan, China |
Brand Name: | xinguang | Model Number: | PE or PEX | Certification: | iso |
Warranty: | 1 year | After-sales Service Provided: | Overseas service center available |
Product Description
High standards of quality famous jaw crusher
The jaw crusher is a kind of crude crushing equipment widely used at home and abroad. It mainly applies for primary and crude crushing of all kinds of hard rocks and block materials . Large and medium-sized jaw crushers are the leading products of our company and have been in the lead now both at home and abroad .
Application:
It is widely applied for primary crushing of hard materials . And it is widely used in the following industries : minerals , quarry,building materials, road , rail way , water conservancy and hydropower , and so on .
Jaw crusher Features:
1. Jaw crusher is simple structure, easy maintenance;
2. Jaw crusher is stable performance;
3. Jaw crusher is even final particles and high crushing ratio.
Operating principle :
The motor drives the belt wheel ,and makes movable jaw up and down by eccentric shaft. When the movable jaw rises , the angle between the fixed jaw and movable jaw gets larger , and the materials can be crushed to reach the crushing target. When the movable jaw is down , the angle between the fixed jaw and movable jaw becomes smaller. The movable jaw plate leaves the fixed jaw plate under the function of drawbar and spring , and then the crushed materials are discharged from the lower outlet of the crushing cavity.
Features: It features of simple structure , large crushing ratio, high output , even particles , convenient maintenance , low production cost and so on .
model
| specification
| Size of the feeder opening L×W(mm)
| Max feeding size (mm)
| Adjusted range of output (mm)
| Capacity(t/h)
| Spindle speed (r/min)
| motor
| Weight (t)
| ||
Model | Power (km) | |||||||||
PE-150 | 150×250 | 250 | 150 | 125 | 15-45 | 1-4 | 285 | Y2-132S-4 | 5.5 | 1000 |
PE-200 | 200×300 | 300 | 200 | 180 | 20-70 | 2-8 | 250 | Y2-160M-4 | 11 | 1500 |
PE-250 | 250×400 | 400 | 250 | 210 | 20-80 | 5-20 | 280-320 | Y2-180L-6 | 15 | 3000 |
PE-400 | 400×600 | 600 | 400 | 350 | 40-100 | 25-64 | 250 | Y2-250M-8 | 30 | 6800 |
PE-500 | 500×750 | 750 | 500 | 425 | 50-100 | 45-75 | 280 | Y2-280M-6 | 55 | 12500 |
PE-600 | 600×900 | 900 | 600 | 500 | 72-160 | 56-192 | 250 | JR117-8 | 80 | 16800 |
PE-750 | 750×1060 | 1060 | 750 | 630 | 80-140 | 80-220 | 250 | YR315S-8 | 90 | 2700 |
PEX-150 | 150×750 | 1000 | 150 | 120 | 10-40 | 8-35 | 300 | Y2-180L-6 | 15 | 3500 |
PEX-250 | 250×750 | 750 | 250 | 210 | 15-50 | 15-45 | 320 | Y2-280S-8 | 37 | 6350 |
PEX-250 | 250×1000 | 750 | 250 | 210 | 15-50 | 13-35 | 300 | Y2-250M-8 | 30 | 6010 |
PEX-250 | 250×1200 | 1200 | 250 | 210 | 15-50 | 20-60 | 320 | J2-280M-8 | 4 | 7700 |
PEX-300 | 300×1300
| 1300 | 300 | 250 | 20-90 | 20-95 | 300 | Y2-315M-8 | 75 | 11302 |
Zhengzhou Xinguang Mining Machinery Manufacturing Co., Ltd was founded in the 1980s, now has become a group company which own many branches in China and abroad. As a professional mining machinery manufacturer, we provides complete sets of mine selection machines, sand making equipment, cement making equipment, and compound fertilizer equipment, with a production capacity ranging from five tons to five thousand tons per day.
Contact Us
- Zhengzhou Xinguang Mining Machinery Manufacturing Co., Ltd.
- Contact nameDamon Yang
- Phone0086-371-64151124
- AddressNanhedu Industrial Zone of Gongyi Zhengzhou,Henan
