Specification
Vibrating screen
1.long life.
2.low noise.
3.reliable performance.
4.high screen efficiency.
Description of Vibrating screen
This series vibrating screen is a new and efficient screening equipment, it is widely used in mining, coal, metallurgy, building materials, chemicals,refractories, light industry and other industries, small particles in the bulk materials and material of group work. It has stable and relisble performance, low consumption, low noise, long life, steady vibration mode,simple structure, beautiful apperance, high screening efficiency.
Working principle of vibrating screen
The vibrating screen consists of screen box, supporting device, vibration exciter, transmission part, etc. The barrel-type vibration exciter is installed in the middle part of the machine. During normal operation, the vibartion of exciter will drive the screen mesh fixed on the screen box vibrate, and then materials will be screened. The big and small materials fall from the upper side and lower side of the screen to get them separated.
Technical Parameter
Model |
Sieve layer |
Sieve area (m²) |
Mesh size (mm) |
Max feeding size (mm) |
Processing capacity (m³/h) |
Vibrating Frequency (r/min) |
Motor power (kw) |
Sieve Size (mm) |
Total weight (kg) |
2YK1237 |
2 |
8.88 |
4-50 |
400 |
15-86 |
800-970 |
7.5 |
1200×3700 |
4600 |
3YK1237 |
3 |
13.22 |
4-50 |
400 |
16-90 |
800-970 |
7.5 |
1500×3500 |
5200 |
2YK1548 |
2 |
14.4 |
5-50 |
400 |
22.5-162 |
800-970 |
15 |
1500×4800 |
6980 |
3YK1548 |
3 |
21.6 |
5-50 |
400 |
22.5-162 |
800-970 |
15 |
1500×4800 |
7700 |
4YK1548 |
4 |
28.8 |
5-50 |
400 |
22.5-162 |
800-970 |
18.5 |
1500×4800 |
8700 |
2YK1848 |
2 |
17.28 |
5-80 |
400 |
25-206 |
750 |
15 |
1800×4800 |
9080 |
3YK1848 |
3 |
25.92 |
5-80 |
400 |
32-276 |
750 |
18.5 |
1800×4800 |
9600 |
4YK1848 |
4 |
34.54 |
5-80 |
400 |
32-285 |
750 |
22 |
1800×4800 |
11100 |
2YK1860 |
2 |
21.6 |
5-80 |
400 |
35-310 |
800 |
18.5 |
1800×6000 |
9700 |
3YK1860 |
3 |
32.4 |
5-80 |
400 |
35-300 |
800 |
22 |
1800×6000 |
11200 |
4YK1860 |
4 |
43.2 |
5-80 |
400 |
35-320 |
800 |
30 |
1800×6000 |
13500 |
2YK2160 |
2 |
25.2 |
5-100 |
400 |
50-475 |
970 |
30 |
2100×2600 |
11780 |
3YK2160 |
3 |
37.8 |
5-100 |
400 |
50-475 |
970 |
30 |
2100×2600 |
12800 |
4YK2160 |
4 |
50.4 |
5-100 |
400 |
50-497 |
970 |
37 |
2100×2600 |
14800 |
2YK2460 |
2 |
28.8 |
5-100 |
400 |
65-550 |
970 |
37 |
2400×6000 |
15600 |
3YK2460 |
3 |
43.2 |
5-100 |
400 |
70-620 |
970 |
37 |
2400×6000 |
17600 |
4YK2460 |
4 |
57.6 |
5-100 |
400 |
80-680 |
970 |
45 |
2400×6000 |
19600 |
