high output ball mill
- 200 Set / Sets per Month
- The two sides to discuss
- T/T Credit Card
Product Details
Condition: | New | Type: | Ball Mill | Motor Type: | AC Motor |
Power(W): | According to model | Capacity(t/h): | According to model | Place of Origin: | Henan, China |
Brand Name: | XinGuang | Model Number: | According to model | Dimension(L*W*H): | According to model |
Weight: | According to model | Certification: | ISO9001:2008 | Warranty: | 365days |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
XinGuang is a professional ball mill manufacturer in China, welcome you visit our company to know more about us.
Detailed Description of super fine ball mill
The ball mill is a key equipment to grind the crushed materials, and the ball mill is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics, etc,.And the ball mill can grind various ores and other materials with dry type and wet type. There are two kinds of ball mill, grate type and overfall type due to different ways of discharging material.
Working Principle
The barrel of grinder is driven by the motor through transmission and reduction gears to rotate at a proper speed. The grinding media in the rotating barrel is lifted to a certain height and then acts by tossing and falling, by which the material is impacted and grinded.
Technical Parameter
Model | Shell rotation speed (r/min) | Ball load (t) | Feeding size (mm) | Discharging size (mm) | Capacity (t/h) | Motor power (kw) | Total weight (t) |
900×1800 | 41 | 1 | ≤15 | 0.075-0.89 | 0.33-1.6 | 15 | 3.8 |
900x2100 | 41 | 1.53 | ≤15 | 0.075-0.89 | 1.5-2.3 | 15 | 4.2 |
900×3000 | 40 | 2.3 | ≤20 | 0.075-0.89 | 1.7-2.5 | 22 | 5.5 |
1200×2800 | 36 | 4.22 | ≤25 | 0.074-0.4 | 1.5-3.7 | 37 | 8.5 |
1200×4500 | 31.3 | 5.2 | ≤25 | 0.074-0.4 | 1.2-7.5 | 45 | 12 |
1500×3500 | 32 | 8.55 | ≤25 | 0.074-0.4 | 3.3-8.2 | 75 | 17 |
1500×4500 | 32 | 9 | ≤25 | 0.074-0.4 | 4-10 | 85 | 20 |
1500×5700 | 29.2 | 14 | ≤25 | 0.074-0.4 | 2-15 | 90 | 22 |
1830×3600 | 26.4 | 10 | ≤25 | 0.074-0.4 | 3.8-12 | 155 | 27 |
1830×4500 | 28 | 15 | ≤25 | 0.074-0.4 | 5-18 | 185 | 31 |
1830×7000 | 27.5 | 21 | ≤25 | 0.074-0.4 | 21 | 245 | 37 |
2100×3600 | 24.1 | 18.6 | ≤25 | 0.074-0.4 | 7.6-42 | 185 | 37 |
2100×4500 | 25 | 22 | ≤25 | 0.074-0.4 | 8-33 | 210 | 45 |
2100×7000 | 24 | 26 | ≤25 | 0.074-0.4 | 8-42 | 280 | 54 |
2200×3600 | 21 | 20 | ≤25 | 0.074-0.4 | 25-40 | 245 | 43 |
2200×4500 | 21.5 | 24 | ≤25 | 0.074-0.4 | 25-45 | 280 | 55 |
2200×7000 | 21.7 | 27 | ≤25 | 0.074-0.4 | 25-58 | 310 | 60 |
2400×3600 | 21.6 | 23 | ≤25 | 0.074-0.4 | 11-52 | 210 | 46 |
2400×7000 | 21 | 39.5 | ≤25 | 0.074-0.4 | 8.5-60 | 245 | 63 |
About Us
Zhengzhou Xinguang Mining Machinery Manufacturing Co., Ltd was founded in the 1980s, now has become a group company which own many branches in China and abroad. As a professional mining machinery manufacturer, we provides complete sets of mine selection machines, sand making equipment, cement making equipment, and compound fertilizer equipment, with a production capacity ranging from five tons to five thousand tons per day.
