Specifications
Flotation Separator,Flotation Machine1.reasonable price
2.well after-sale service
3.low cost
4.ISO9001-2000
Flotation Separator,Flotation Machine
Floatation Separator is applicable for separating non-ferrous metal, black metal, noble metal, non-metal mineral, raw body and materials of chemical industry, which are subject to coarse separation, swept separation, fine separation and floatation, so the useful ore are reclaimed.
Flotation Separator,Flotation Machine
The Floatation Separator has the advantages of large air-absorption capacity and low energy consumption. Every cell owns three functions: air absorption, slurry absorption, and floatation separation, and the cells form a floatation separation loop by itself without any auxiliary equipment, and is allocated horizontally, which favors the change of flow. The circulation of mineral slurry is reasonable, and can avoid the disposition of coarse sand to the largest extent. There is self-control device on the surface of mineral slurry, so it is easy to adjust it. The impeller has backward-inclined upper and lower vanes, which produce upper and lower circulation of mineral slurrry respectively.
Flotation Separator,Flotation Machine
Flotation Separator is applicable for the separation of nonferrous metal and ferrous metals, such as fluorite and talc. The impeller is driven by V-belts, which can bring the centrifugal effect to form negative pressure. While extracting sufficient air to mix with ore pulp, the machine stirs ore pulp and mixes it with chemicals to form mineralized froth. By adjusting the height of the flash board to control the liquid level, the useful froth can be scraped from the loam board. The height of the strobe must be adjusted carefully to keep the stabilization of liquid level and scrape the mineralized froth to the launder. The impellers and stators should be kept at a distance and should be changed when worn. The bearing in the pump should be maintained every three months.
Flotation Separator,Flotation Machine
Model |
XJK-0.35(3A) |
XJK-0.62(4A) |
XJK-1.1(5A) |
XJK-2.8(6A) |
XJK-5.8(7A) |
SF1.2 |
SF2.8 |
SF4.0 |
SF8.0 |
||
Effective volume(m3) |
0.35 |
0.62 |
1.1 |
2.8 |
5.8 |
1.2 |
2.8 |
4 |
8 |
||
Capacity (t/h) |
0.18-0.4 |
0.3-0.9 |
0.6-1.6 |
1.5-3.5 |
5-7 |
0.7-1.8 |
1.6-3.8 |
2-4 |
4-8 |
||
Speed (r/min) |
470 |
400 |
330 |
280 |
240 |
325 |
270 |
220 |
191 |
||
Impeller diameter(mm) |
300 |
350 |
500 |
600 |
750 |
500 |
600 |
650 |
760 |
||
With motor |
Model |
Rotor |
Y90L-4 |
Y100L2-4 |
Y132M2-6 |
Y160L-6 |
Y200L2-6 |
Y132M-6 |
Y160L-6 |
Y200L-8 |
Y250M-8 |
Scraper |
Y802 |
Y90S |
Y90L-6 |
Y90L-6 |
Y90L-6 |
Y90L-6 |
Y90L-6 |
Y100L-6 |
Y100L-6 |
||
Power (kw) |
1.5 |
3 |
5.5/1.1 |
11/1.1 |
22/1.5 |
5.5/1.1 |
11/1.1 |
15/1.5 |
30/1.5 |
||
Weight (t/trough) |
0.43 |
0.86 |
1.38 |
2.33 |
1.38 |
1.44 |
2.40 |
2.66 |
4.129 |
||
