Home > Manufacturing & Processing Machinery > Machine Tools > Boring Machine > CTQ-D100YA2 Dirlling Rig

CTQ-D100YA2 Dirlling Rig

Name: CTQ-D100YA2 Dirlling Rig
Brand: longye
SKU: 141558556
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

CNC or Not:

Normal

Place of Origin:

Shandong, China

Contact Supplier Request Quote Chat Now

Shandong Longye Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

CNC or Not Normal

Place of Origin Shandong, China

Brand Name longye

Model Number CTQ-D100YA2

Weight 2800kg

Specifications

CTQ-D100YA2 blasting drilling rig,low air pressure hydraulic drilling rig

CTQ-D100YA2 crawler hydraulic drilling rig,adopt new-style hydraulic technique which have low air consumption,large rotation torque.the structure of the drilling rig is compact,The minimum circumgrating radius is 2.8m,During drilling the slide-skid are support on the ground to ensure the drilling has good stability.

Walking system adopt a large torque agencies to ensure that a strong driving force for the output.

Elevating and push system use the realiable performance fuel tank to complete working.

Ratation system can change the speed easily,It fulill different requirements in different working conditions.

The usage o double-pump reduce the cost o damage odds and maintance costs.

Total weight	2800kg
Bore diameter	90-130mm
Dimension	410020302020
Bore depth	30m
Travelling speed	2km/h
Climb ability	30°
Feed stroke	2000mm
Working pressure	0.7-1.0Mpa
Ground clearance	250mm
Air consumption	7-10m3/min
Slip frame pitch degree	Up and down 100 degree each
Slide kid slanting allowance	Left 35 degree right 10 degree
Rated motor power	33kw
