Gold Mining Blasting Hole Drilling Rig CTQ-G140YF
- qingdao
- T/T Money Gram
You May Like
-
Hydraulic Rock Drill CTQ-G150Y for Sale
-
DTH Gold Mining Drilling Rig With Dust Collector
-
Hydraulic Mining Drilling Rig With Dust Collector
-
CTQ-D100YA2 Crawler Hydraulic Rotary Drilling Rig
-
CTQ-G150YF Crawler Hydraulic Blasting Hole Rotary Drilling Rig
-
CTQ-Z115Y Crawler Hydraulic Rotary Down-hole Drilling Rig
Product Details
| Condition | New | Type | Other, DTH drilling rig | |
| Power Type | Diesel | Brand Name | longye | |
| Model Number | CTQ-G140YF | Usage | Other | |
| Voltage | 220v | Power(W) | 56kw | |
| Dimension(L*W*H) | 5270*1960*2300 | Weight | 4800KGS | |
| Certification | CE | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
CTQ-G140YFgold mining blasting hole drilling rigdepth:60m
hole dia:115-140mm
CTQ-G140YF gold mining blasting hole drilling rig
Application :
CTQG140Y Hydraulic Crawler drilling rig,using new type hydraulic technology,low consumption,large rotary torque.the rig structure is compact.when drilling,the mast supported on the ground,borehole stability is good.
CTQG140Y mainly use for open mining DTH blasting construction,electrical power stations ,road building etc.
specification:
Working pressure | 1.05-2.46Mpa |
Air consumption | 10-20m³/min |
Drilling diameter | 115/140mm |
Drilling depth | 60m |
Drill pipe diameter | 76mm |
Once promotion distance | 3000mm |
Rock (f) | f=6-20 |
Climb ability | 40° |
Total weight | 4.8T |
Walking speed | 0---2.5km/h |
Rotary speed | 0---126r/min |
Mast pitch | Up and down100° |
Mast slide | Up and down 100° |
Zoom pitch | Up and down 60° |
Zoom slide | Left and right 70° |
Outside dimension | 5270X1960X2300 |
Hose power | 56KW |
