Steam boiler
Usage: The steam boiler can be used for producing desired hot water for product manufacturing process in the weave factory, printing and dying, papermaking, and rubber, plastic chemical, pharmaceutical, etc. And for heating room, bath, air conditional, and daily life water in the factories, departments, hotels, schools, restaurants, services industries etc.
The Advantages:
1.Combustible gas is burned out under effect of intensive secondary air and rotation deviding of multi-layer tubes. Thermal decomposition to carbon black because of lack of oxygen is avoided.
2.Coal layer is thicker and coal surface smaller than conventional boiler coal layer. Besides primary air volume is only 50%-60% of the total air volume.So th initial boiler soot emission concentration is lower than conventional.
pact structure, convenient installation and moving
4.Multi-trip cycling enables self-dedusting
5.Water seal avoid soot spreading.
6.Gasification burning saves more than 15% fuel.
| Model | LSB0.5-0.4-WII | LSB0.6-0.4-WII | LSB0.7-0.4-WII | LSB1-0.4-WII | LSB0.5-0.7-WII | LSB0.6-0.7-WII | LSB0.7-0.7-WII | LSB1-0.7-WII |
| Rated evaporation capacity(t/h) | 0.5 | 0.6 | 0.7 | 1 | 0.5 | 0.6 | 0.7 | 1 |
| Rated working pressure(Mpa) | 0.4 | 0.4 | 0.4 | 0.4 | 0.7 | 0.7 | 0.7 | 0.7 |
| Rated steam temperature('C) | 151 | 151 | 151 | 151 | 170 | 170 | 170 | 170 |
| Fuel | WII | |||||||
| Reference weight(t) | 2.8 | 3.4 | 4.2 | 6.2 | 3.1 | 3.6 | 4.6 | 6.8 |
| Diameter size(mm) | 1300 | 1300 | 1400 | 1600 | 1300 | 1300 | 1400 | 1600 |
| Height size(mm) | 3600 | 3800 | 4000 | 4400 | 3700 | 3900 | 4200 | 4600 |
| Elucidation:1.data and pictures in watch provide the reference only,the product takes real object as to follow,forgiving not to go to another circula such as the alteration because of remodel 2.prepare to make,reserve,and design of the boiler building,pleased contact to confirm before relevant data. | ||||||||
1. Capacity: 0.5-1.5Ton/hr
2.Rated working pressure: 0.4-1.5Mpa (4-15kgf/cm2)
Can be adjusted according to customer’s demand
3.Fuel: Coal & Wood
4.Thermal Efficiency: ≥90%
5.Power Supply: Three phase 380V, 50Hz Can be adjusted to 400 Volt , 415 Volt or 420 and adjusted to 60Hz
6.Saturated steam temperature: 1500-194°c
