Wood steam boiler
Usage: The steam boiler can be used for producing desired hot water for product manufacturing process in the weave factory, printing and dying, papermaking, and rubber, plastic chemical, pharmaceutical, etc. And for heating room, bath, air conditional, and daily life water in the factories, departments, hotels, schools, restaurants, services industries etc.
The Advantages:
1.energy conservation and environment protection: adopt the newest gasification burning technology ,
design advantage gasification rotation combustor ,there are rotational flow second wind to burn enough .
Adopt with high efficiency heating elements ,-spirally corrugated tube to match with reasonable smoke
flow speed ,to be high efficiency ,it can get above 85%
The boiler use the biomass which is country spread as fuel ,Co2 is zero emission ,the dust emission
concentration is less 50mg/m3 ,the darkness is less Ringlemann number I grade ,every index can
get the national I area Environmental standard.
2 Low operating cost ,the wood biomass is newest environmental fuel ,renewable resource .Its feature
is high calorific value ,low cost ,a variety of source ,the operation cost is only a quarter of electric boiler.,
half of the oil boiler .
3. High automatic :digital integrated controller ,the user can control it by requirement .It light the fire
by itself ,feed by itself ,discharge by it self .
4. Safety ,match with high standard and high quality auxiliary engineer .
5. Novel appearance .
| model | rated capacity (t) | rated working pressure (Mpa) | rated steam temperature(°C) | heating area (m2) | fire grate area(m2) | discharge temperature(°C) | heat efficiency(%) | size (m) |
| DZH1-0.7-T | 1 | 0.7 | 170 | 45.6 | 1.8 | 146 | 82% | 4.2*2.0*2.8 |
| DZH1-1.25-T | 1 | 1.25 | 194 | 52.9 | 1.8 | 132.1 | 82% | 4.2*2.0*2.9 |
| DZH2-0.7-T | 2 | 0.7 | 170 | 82 | 3.36 | 152.6 | 82% | 5.1*2.4*3.2 |
| DZH2-1.25-T | 2 | 1.25 | 194 | 82 | 3.36 | 162 | 82% | 5.1*2.4*3.2 |
| DZH4-1.25-T | 4 | 1.25 | 194 | 131.4 | 4.8 | 156 | 82% | 5.78*2.6*3.24 |
| DZH6-1.25-AIT | 6 | 1.25 | 194 | 243.6 | 7.16 | 126.6 | 82% | 6.75*2.85*3.65 |
| model | rated capacity (t) | rated working pressure (Mpa) | rated steam temperature(°C) | heating area (m2) | fire grate area(m2) | discharge temperature(°C) | heat efficiency(%) | size (m) |
| DZL1-0.7-T | 1 | 0.7 | 170 | 45.6 | 1.8 | 136 | 82% | 4.7*2.0*2.9 |
| DZL1-1.25-T | 1 | 1.25 | 194 | 52.9 | 1.8 | 128 | 82% | 4.7*2.0*2.9 |
| DZL2-0.7-T | 2 | 0.7 | 170 | 82.08 | 3.36 | 158.3 | 82% | 5.4*2.4*3.5 |
| DZL2-1.25-T | 2 | 1.25 | 194 | 89.4 | 3.45 | 157 | 82% | 5.4*2.4*3.5 |
| DZL4-1.25-T | 4 | 1.25 | 194 | 136.3 | 5.9 | 162.3 | 82% | 6.2*2.95*3.35 |
| DZL4-1.6-T | 4 | 1.6 | 194 | 136.3 | 5.9 | 165.4 | 82% | 6.2*2.95*3.35 |
| DZL6-1.25-AIT | 6 | 1.25 | 194 | 217.9 | 8.2 | 121.1 | 82% | 7.8*2.85*3.65 |
| DZL6-1.6-AIT | 6 | 1.6 | 204 | 217.9 | 8.2 | 126.2 | 82% | 7.8*2.85*3.65 |
