1575mm fourdrinier paper machine 5-6 T/D printing paper making machine
- 15 Set / Sets per Month
- qingdao port /Shanghai .Tianjin
- T/T L/C
- 1575mm fourdrinier and double-dryer paper machine 5-6 T/D printing paper(copy paper) making machine
- 1092mm paper wideth 4-5 t/d capacity a4 printing paper making machine
- 1880mm a4 paper, writing paper and copy paper daily 20 tons paper manufacturing machine
- 2100mm a4 paper, writing paper and copy paper making and recycling machine, whole production line
- 2100mm culture paper office copy/printing paper making machine
- 2100mm culture paper office copy paper making machine
Product Details
Condition: | New | Product Type: | Other, a4 paper /copying & printing paper machine | Processing Type: | Other, culture paper making machine |
Place of Origin: | Henan, China | Brand Name: | Jinhua | Model Number: | 1575mm |
Voltage: | 380v | Power(W): | 260kw | Dimension(L*W*H): | 12m*5m*3m |
Weight: | 12T | Certification: | Other, ISO9001:2008 | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Container
Product Description
1575 mm fourdrinier and double-dryer paper machine culture paper machine
Brief Introduction :
Cultural paper machine includes the model 1092mm,1575mm,1880mm,2400mm,3200mm, etc. It can make cultural paper,newspaper,writing paper, printing paper((A3,A4paper)), transfer printing paper (A3,A4paper) , flat paper and so on.The capacity is from 5 tons to 50 tons per day.
The parameter of 1575 mm culture paper machine:
1.raw material:waste paper pulp,wood plup,bamboo pulp
2.Output:newspaper,writing paper,printing paper, transfer printing paper (A3,A4paper) ,
3.Output: paper weight: 40-120 g/m
paper width: 1600mm
5.Capacity:5-6 ton per day
6.Width of cylinder mould: 1950 mm
7.Rail gauge: 2400 mm
8. Drive way: AC frequency conversion speed, section drive
structure of main part:
1.Cylinder section: Φ1500mm×1950mm stainless steel cylinder mould 2 sets, Φ450mm×1950mm couch roll 2 set, φ400×1950mm reverse roll 1set, coated by rubber,rubber shore hardness 38°C±2.pneumatic loading device.
2.Press section: Φ500mm×1950mm marble roll 1 set, Φ450mm×1950mm rubber roll 1 set, coated by rubber,rubber shore hardness 90°C±2.
3.Dryer section:Φ2500mm×1950mm alloy dryer can 1 set, Φ1500mm×1950mm alloy dryer can 3 set,Φ500mm×1950mm touch roll 1 set,coated by rubber,rubber shore hardness 90°C±2.
4.Drive way :AC frequency conversion speed, section drive
5. Pneumatic compression device.
All equipments list:
NO. | Item | Qty(set) |
1 | 1575mm office paper machine | 1 |
2 | 15 type roots vacuum pump | 1 |
3 | Suction box | 2 |
4 | 5m3 High consistency hydrapulper | 1 |
5 | 1.8m2 High frequency vibration screen | 1 |
6 | Φ380mm double disc pulp refiner | 1 |
7 | 606sander remover ( 6 pcs) | 1 group |
8 | 6 inch pulp Pump | 3 |
9 | 4 inch pulp Pump | 2 |
10 | Φ700mmThruster Φ700mm | 4 |
11 | 1575mm cutting machine | 1 |
12 | 35m3Bleacher | 1 |
13 | 0.9m3 Centrifugal screen | 1 |
14 | 2T Boiler(burn coal) | 1 |
Raw material:
Output paper :
Our Factory :
Contact information :
Company Profile
Gongyi Jinhua Machinery Manufacturing Co., Ltd. is a joint venture which mainly produces complete equipment of equipment of pulping and paper machine complete equipment,waste recycling plant,shredder machine,crusher machine,agricultural drying machine .
Our company is located in China's transportation hub in Zhengzhou city, founded in 1980. The production facility covers an area of 8,600 square meters with a construction area of 20,800 square meters. With the management idea of sincerity, after thirty years of continuous development and strength, now we employ over 500 full time staff members with more than 100 professional technicians. We also employ 50 staff members who are translators, salespersons, electronic commerce persons. Our company is an integrated industrial enterprise of scientific research, product development, manufacturing and sale.
Our company has modern management systems, advanced manufacturing technology, complete testing methods, a large number of excellent processing equipment and high-quality skilled workers. All products pass ISO9001:2008 international quality authentication. Our products are sold throughout the world, including Canada,America,South America,Gremany,France,England, Southeast Asia, Bangladesh, Indonesia, Pakistan, Egypt, Syria, Mexico, Nigeria, Russia, etc. Our company wins customers' trust and recognition widely with integrity, pragmatism, refinement development and eternal commitment.
Our company offers an exceptional service team of sale and technology, who offers program and craft process design, technical training and so on. We also offer service of pre-sales, in-sales and after-sales.
