2015 latest design sand brick making machine/sand making machinery
Sand brick making machine/sand making machinery
Description of sand making machine
Our Sand making machine is especially efficient to crush harder and causticity materials, such as carborundum, emery, and magnesium sand. HengJi Series Sand Making Machine is one of the most advanced impact crushers nowadays. It introduces high quality roller bearings like Sweden SKF and America TIMKEN, which ensure the smooth running of main unit. Personalized design is used in upper cap, sand making machine is easy and convenient to maintain and replace spare parts. Sand Making Machine is our sole patent using central feeding & central cascade feeding, which can be changed based on customers' needs.
Sand brick making machine/sand making machinery
working principle of sand making machine
Sand making machine lets materials fall into the crusher and are divided into two parts. One part goes into the high-speed-running impeller of the machine, and the other part goes around the impeller. The two parts materials bump and crush fast during the effect of centrifugal force. Then the materials run like swirl, bump and rub to each other again and again. The finished products go out from the bottom of the machine, and users can get the requested products size after screening by vibrating screen.
Sand brick making machine/sand making machinery
Complete of sand making machine line
Sand brick making machine/sand making machinery
application of sand making machine
1, river pebbles, rocks (granite, limestone, andesite, diabase, Xuan Wuyan, etc.), ore tailings, stone chip of artificial sand.
2, construction aggregate, highway road fabric, cushion material, asphalt concrete and cement concrete aggregate production.
3, in the field of water conservancy and Hydropower Engineering, highway, high-speed railway, passenger dedicated line, bridge, airport runway, municipal engineering, high-rise building mechanism of sand production and stone plastic.
4,Grinding PPK finely process of the mining sector, building materials, metallurgy, chemical, mining, cement, refractory material, abrasive etc material breakage.
Sand brick making machine/sand making machinery
Model parameter of sand making machine
| Model | VSI-7611 | VSI-8518 | VSI-9526 | VSI-1140 | ||
| Capacity (t/h) |
Center and Sides Feeding | 120-180 | 200-260 | 300-380 | 450-520 | |
| Center Feeding | 60-90 | 100-130 | 150-190 | 225-260 | ||
| Max. Feeding Size (mm) | Soft Material | 35 | 40 | 45 | 50 | |
| Hard Material | 30 | 35 | 40 | 45 | ||
| Rotation Speed(rpm) | 1700-1890 | 1520-1690 | 1360-1510 | 1180-1310 | ||
| Double Motor Power (kw) | 110 | 180 | 264 | 400 | ||
| Overall Dimension L×W×H (mm) |
3700×2150×2100 | 4140×2280×2425 | 4560×2447×2778 | 5000×2700×3300 | ||
| Weight (t) | 7.8 | 10.3 | 16 | 25.6 | ||
| Vibrating Sensor | Inspection Range: 0.1-20mm/s Continual Adjustment | |||||
| Hydraulic Oil Pump | Motor Power of Double Oil Pump(Kw) | 2×0.31kw | ||||
| Overall Dimension L×W×H (mm) |
820×520×1270 | |||||
| Power of Oil Tank Heater | 2KW | |||||
Sand brick making machine/sand making machinery
Packaging & delivery
Sand brick making machine/sand making machinery
Manufacturing shop of sand making machine
Sand brick making machine/sand making machinery
After-sales Service:
a.Highly inspecting equipments in every working procedure, quality comes first;
b.Fast & Safe Delivery;
c.Assisting our clients for foundation construction of equipments;
d.Dispatching engineers to install and debug equipments;
e.Training the first-line operators on site.
f.The guarantee period for equipment is one year,excluding wearing parts.During this period,if any defects,the seller will resolve them free of charge.
Sand brick making machine/sand making machinery
Company information
Gongyi Jinlong Hengji Heavy Machinery Co. Ltd. is a professional production of large and medium crushing, grinding,sand making machine,pelletizing machine equipment research, production,marketing trinity of the private sector. Company headquarters is located in a blend of traditional and innovative mechanical Gongyi City Industrial Development Zone,over the years , the company adhering to the scientific management of modern enterprises , precision manufacturing , forge ahead , innovation, rapid rise to become the leader in equipment manufacturing deserved.
Sand brick making machine/sand making machinery
Contact me
Sand brick making machine is selling and price cheap.If you have any questions,please contact me freely.
