High efficiency sand maker,sand making machine price for sale
Sand making machine is the latest product of authoritative experts from Germany, connecting with Chinese present working conditions. It’s the high—efficiency sand making equipment with advanced world levels in our country. It is the preferred equipment for artificial sand making and stone reshaping industry. It specially provides the best material for the highway, railway, high-rise buildings, municipal works, hydro-electric dam and concrete mixing station. It ranks first among similar products with its excellent cost performance and reliability.
Simple structure and low operating cost; High efficiency and low consumption; sand crusher has the function of fine crush and cude grinding; slightly influenced by the moisture content of material and the max moisture content is 8%;More suitable for crushing mid-hardness and high-hardness materials' Cubic shape of final products, high density of piling up and low iron pollution; More wearable and easy maintenance; Low working noise and light dust pollution.
When the material taken into the feed hopper, through the center feeding hole fall into the high-speed rotation of the rotor was sufficiently accelerated and by emission mouth out, first impact with a part of materials of the free falling after rebound, and then impact to the vortex shaped material around the vortex cavity lining (or counter block), is first bounced back to the top after the crushing cavity, partial steering movement, forming a continuous material curtain and launch out from the impeller material impact, finally through the lower part of the discharge port discharge.
Sand crusher can be used in Pebble,rock( the limestone, granite, basalt, aluminum, andesite, etc.), ore tailings, slags, artificial sand production. can be used in Building aggregate, highway, asphalt concrete and cement aggregate production.As well as stone reshaping production in water conservancy and hydropower engineering field,highway, railway, bridge, passenger line, airport runway, municipal engineering and high-rise buildings.finely process of mining areas. Building materials,mining,metallurgy, chemical industry,cement,abrasive,refractory material, etc.With high abrasive materials resistance and secondary disassembly, desulphuration of thermal power and metallurgy, slag and construction waste. Also can be used in the production of glass,quartz sand and other high purity material.
| Model | VSI-7611 | VSI-8518 | VSI-9526 | VSI-1140 | ||
| Capacity (t/h) |
Center and Sides Feeding | 120-180 | 200-260 | 300-380 | 450-520 | |
| Center Feeding | 60-90 | 100-130 | 150-190 | 225-260 | ||
| Max. Feeding Size (mm) | Soft Material | 35 | 40 | 45 | 50 | |
| Hard Material | 30 | 35 | 40 | 45 | ||
| Rotation Speed(rpm) | 1700-1890 | 1520-1690 | 1360-1510 | 1180-1310 | ||
| Double Motor Power (kw) | 110 | 180 | 264 | 400 | ||
| Overall Dimension L×W×H (mm) |
3700×2150×2100 | 4140×2280×2425 | 4560×2447×2778 | 5000×2700×3300 | ||
| Weight (t) | 7.8 | 10.3 | 16 | 25.6 | ||
| Vibrating Sensor | Inspection Range: 0.1-20mm/s Continual Adjustment | |||||
| Hydraulic Oil Pump | Motor Power of Double Oil Pump(Kw) | 2×0.31kw | ||||
| Overall Dimension L×W×H (mm) |
820×520×1270 | |||||
| Power of Oil Tank Heater | 2KW | |||||
After-sales Service:
a.Highly inspecting equipments in every working procedure, quality comes first;
b.Fast & Safe Delivery;
c.Assisting our clients for foundation construction of equipments;
d.Dispatching engineers to install and debug equipments;
e.Training the first-line operators on site.
f.The guarantee period for equipment is one year,excluding wearing parts.During this period,if any defects,the seller will resolve them free of charge.
Welcome to visit our factory! We will provide you our best equipments at the
reasonable price to meet your requirment.
Sand making machine price is hot sale, preferential prices tend to produce in communication.
