Laboratory Chilling Recirculator
Brief introduction
Laboratory chilling recirculator--adopt mechanical refrigeration, the main function is to provide low temperature liquid for rotary evaporator, glass reactor and so on to achieve the chemical reaction under low temperature condition.It is particularly suitable for the chemistry, biology, food industry, metallurgical industry, scientific research, genetic engineering, polymer engineering when need to maintain low temperature.
Features
1. High Quality Air-cooled hermetic imported compressor group.
2. Exclusive and high quality relay, protector, and capacitor.
3. Microprocessor controller, displays display, simple operation.
4. Large cooling capacity and high cooling speed
5. Circulation pump flow can be customized to meet the practical needs of different customers.
6. All models of the machine temperature and cooling capacity can be customized to meet the customer's actual needs.
7. The evaporation rate of plate type refrigerate circulators can rise up 50% than normal
refrigerate circulators.
♦ According to the volume of the cryogenic cooling bath circulation pump divided into divided into : 5L,
10L, 20L, 30L, 40L, 50L, 60L, 80L, 100L.
Each volume according to the lowest temperature can divide into : -10℃, -20℃, -25℃ , -30℃, -40℃, -60℃, -80℃, -120℃.
5L technical parameter
Model |
DLSB-5/10 |
DLSB-5/20 |
DLSB-5/25 |
DLSB-5/30 |
DLSB-5/40 |
DLSB-5/60 |
DLSB-5/80 |
DLSB-5/120 |
|
|
Refrigerant Performance
|
Volume(L) |
5 |
|||||||
No Load Min. Temp. (℃) |
-15 |
-24 |
-27 |
-33 |
-42 |
-62 |
-82 |
-123 |
|
Cooling Capacity (W) |
1328-319 |
1328-319 |
1894-447 |
2733-627 |
2036-602 |
2036-330 |
2036-180 |
3888-160 |
|
|
Circulating Performance
|
Flow(L/min) |
20 |
|||||||
Lift(m) |
4-6 m |
||||||||
|
Temperature Control Performance
|
Coolant Temp. (℃) |
-10 |
-20 |
-25 |
-30 |
-40 |
-60 |
-80 |
-120 |
Temp. Precision (℃) |
±0.2 |
||||||||
|
Working Condition
|
Power Supply |
220V/50Hz |
220V/50Hz or380V/50Hz |
||||||
Environment Temp (℃) |
25 |
||||||||
Environment Humidity |
(60-80%) Ventilation |
||||||||
|
Machine Dimensions
|
Length (mm) |
500 |
500 |
545 |
545 |
600 |
680 |
700 |
950 |
Width (mm) |
370 |
370 |
370 |
370 |
410 |
500 |
650 |
710 |
|
Height (mm) |
540 |
540 |
640 |
640 |
670 |
780 |
900 |
940 |
|
Large volume
Cooling chiller
Packaging
-Wooden case packaging;
-Both neutral and customized packaging can be available.
Shipping
-We can ship the goods to you by International Express such as DHL, TNT, EMS, FedEX and so on and you can also choose the appropriate one based on your timeline and budget. Besides, you can definitely choose to use your own shipping agent.
Service promise
1. Products quality guarantee is for one year, after the product was sold.
2. In the warranty period, the users operate according to instruction but meet problems, our company will maintain free of charge.
3. Beyond the warranty period, products problems can also be solved by my company maintenance, but charge wiring components fees properly.
Technology service
1. We have a mobile repair service team in our company, to carry out maintenance, consulting services in china for many years.
2. Users encounter problems when using our products, please contact us by telephone or email, we will be ready to provide consulting, maintenance and other services immediately.
CE certification
Zhengzhou Keda Machinery and Instrument Equipment Co., Ltd.
Our company always adheres to the "quality casting brand, professional achieves service"
business philosophy, and the main product is rotary evaporator, jacketed glass reactor, single layer glass reactor, circulating water vacuum pump, low temperature reaction bath (slot), cooling chiller, vacuum drying oven, blast drying oven, high-pressure reaction kettle, freeze dryer(lyophilizer), water/oil bath, magnetic heating stirrer, hydrothermal synthesis reactor, heating mantle, lift jack, etc.
Business Type: Manufacturer, Trading Company.
Location: Henan, China (Mainland).
Year Established: 2009.
Total Revenue : US$1 Million - US$2.5 Million.
Registration No: 410105000067362.
Main Markets: Central America, Mid East, Oceania, Africa, South America and so on.
1. How can I choose a reasonable model from so many models ?
We can supply temperature range from - 10 to -120 Celsius degree; Capacity from 5L-100L.
2. OEM is ok?
Yes, we can do artwork including printing, logo etc. for you, if you provide us the content and tell us where to put.
3. My location voltage is 110V, how can we handle this ?
Don’t worry! you can equipped with a voltage regulator or we can customized 110V for you (quantity exceed 10 sets ).
4. What’s the transportation mode you can choose?
For small orders, we will send the goods by International Express like Fedex, DHL, TNT or UPS. Usually it takes 2-7 working days to arrive. If big quantity we will ship by Ocean transportation, it takes one month to arrive. If urgent,
you can select shipping by Air, but freight charge will be more expensive than sea transporation.
